ISE35
N
25
M
L
A
Note 1) This product is for overseas use only according to the new Measurement Law. (The SI unit type is
provided for use in Japan.) Name plate is included.
Note 2) Instruction manual is attached.
Note 3) When ordering the body only, select the symbol from to respectively.
+
+
+
+
0 to 1 MPa
–0.1 to 1 MPa
1.5 MPa
0.01 MPa
12 to 24 VDC, Ripple (p-p) 10% or less (with power supply polarity protection)
55 mA or less (at no load)
NPN or PNP open collector 1 output
80 mA
30 V (with NPN output)
1 V or less (with load current of 80 mA)
1
s
(Response time selections: 0.25, 0.5, 2, 3)
With short circuit protection
±1%F.S. or less
Variable (can be set from 0)
3-digit, 7-segment indicator, 2-color display (Red/
Green) can be interlocked with the switch output.
±2%F.S. ±1 digit (at 25°C ± 3°C)
Illuminates when output is turned ON. (Green)
IP40
ø3.4 3-wire 25AWG 2
m
Rated pressure range
Set pressure range
Withstand pressure
Set pressure resolution
Power supply voltage
Current consumption
Switch output
Repeatability
Display
Display accuracy
Indication light
Lead wire with connector
Environmental
resistance
Hysteresis
Max. load current
Max. applied voltage
Residual voltage
Response time
Anti-chattering function
Short circuit protection
Hysteresis mode
Window comparator mode
Enclosure
Specifications
Description
Wiring bottom entry
Wiring top entry
Symbol
N
R
25
65
Electrical entry
Output
Lead wire
Accessories
With unit conversion function
Fixed SI unit
Pressure unit: psi (initial value) with unit conversion function
—
Note 1)
M
P
Note 1)
Display unit
Note 1)
NPN output
PNP output
—
L
Without lead wire
Lead wire (2 m) with connector
—
A
Without accessories (switch body only)
With accessories (adapter, O-ring (1 pc.), mounting screw (2 pcs.), lock pin)
Applicable Series
AC20, AC25, AC30, AC40, AC50, AC55, AC60
AC20A, AC30A, AC40A, AC50A, AC60A
AC20C, AC25C, AC30C, AC40C
AC20D, AC30D, AC40D
AR20(K), AR25(K), AR30(K), AR40(K),
AR50(K), AR60(K)
AW20(K), AW30(K), AW40(K), AW60(K)
AWM20, AWM30, AWM40
AWD20, AWD30, AWD40
AC20B, AC25B, AC30B, AC40B,
AC50B, AC55B, AC60B
F.R.L. unit
Regulator
Filter regulator
Mist separator regulator
Micro mist separator
regulator
Diigtal Pressure Switch Details
Lock pin
Adapter
M3 x
7
(Screw for aluminum materials)
O-ring
Lead wire
Digital pressure switch
(Body only
)
Example)
Regulator
O-ring
Wiring
bottom entry
Wiring
top entry
Digital pressure switch
(Body only
)
Option
Digital Pressure Switch
NPN open collector
Max. 30 V, 80 mA
Residual output voltage 1 V or less
PNP open collector
Max. 80 mA
Residual output voltage 1 V or less
+
–
+
–
12 to 24 VDC
Load
Brown DC (+)
Black OUT
Blue DC (–)
Brown DC (+)
Black OUT
Blue DC (–)
Load
12 to 24 VDC
Main circuitMain circuit
Output
Lock (supplied by customers)
Lock cover
Keyhole dia.: ø8
Prevents careless knob operation.
Applicable model
AR40P-580AS
AR30P-580AS
AR20P-580AS
AR25P-580AS
Part no.
AC20, AR20(K), AW20(K).
AWM20, AWD20
AC30
, AR30(K), AW3(K),
AWM30, AWD30
AC40
(-06), AR40(K)(-06),
AW40(K)(-06), AWM40,
AWD40
AC25
, AR25(K)
Option
