Copyright Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice. Copyright © 2011 by SMC Networks, Inc. All rights reserved.
LIMITED WARRANTY Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term.
WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, CUSTOMER.S SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC.S OPTION. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Compliances Federal Communication Commission Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
• • • • • • • Electrostatic Discharge according to EN 61000-4-2: 2001 ED.1.2 (Contact Discharge: ±4 kV, Air Discharge: ±8 kV) Radio-frequency electromagnetic field according to EN 61000-4-3: 2006 ED.3.0 (80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m) Electrical fast transient/burst according to EN 61000-4-4: 2004 ED.2.0 (AC/DC power supply: ±1 kV, Data/Signal lines: ±0.5 kV) Surge immunity test according to EN 61000-4-5: 2005 ED.2.
FCC Certifications This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Introduction SMCGS501/SMCGS801 is a powerful, high-performance Gigabit Ethernet switch, with 5/8 ports capable of 10/100/1000 Mbps auto-negotiation operation (NWay), which means the switch could automatically negotiate with the connected partners on the network speed and duplex mode. It is ideal for micro-segmenting large networks into smaller, connected subnets for improved performance, enabling the bandwidth demanding multimedia and imaging applications.
Key Features Complies with 10BASE-T specifications of the IEEE802.3 standard Complies with 100BASE-TX specifications of the IEEE802.3u standard Complies with 1000BASE-T specifications of the IEEE802.3ab standard 5/8 - 10/100/1000Mbps RJ-45 ports Supports MDI/MDI-X auto crossover Supports full and half duplex operation on all ports Supports back-pressure (half duplex) and full duplex flow control (IEEE 802.
LEDs Definition The switch contains one power LED for the device, Link/Act LED for each port that shows the activities and information of the ports.
Station Connection Connect each station to the switch by twisted-pair cable. Plug one RJ-45 connector into a RJ-45 port of the switch, and plug the other RJ-45 connector into the station’s network adapter. Power on the switch and then system is ready. Switches Connection In making a switch interconnection, you could use any port to connect another switch with straight or crossover cable.
Product Specifications Standard IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3ab 1000BASE-T IEEE802.3x full duplex flow control Pre-IEEE 802.3az IEEE 802.1p QoS Interface 5/8* 10/100/1000 Mbps RJ-45 ports Network Data Rate 10/100/1000 Mbps Auto-negotiation Transmission Mode 10/100Mbps: Full-duplex, Half-duplex 1000Mbps: Full-duplex Switching Capacity 5 Port:10Gbps 8 Port:16Gbps Switching Forwarding 5 Port: 7.4Mpps Rate 8 Port: 11.
