Datasheet

Cylinder tube
Tie-rod guide
Air-operated type Max. operating pressure
1.6
MPa
Fourfold pressure
increase type
Booster Regulator Series VBA
Space saving when installed has
been realised.
Elbow silencer added
∗
(Option)
1/8" gauge ports
• Allows use of standard fittings for remote
pressure monitoring, etc.
∗ Gauge ports changed from 1/16" to 1/8" (VBA1쏔A, 2쏔A)
• Floating piston structure (PAT. PEND)
• Grease retaining groove
∗
∗ Except VBA10A, 11A
Improved
service life
that of the conventional model
that of the conventional model
Doubled
Doubled
that of the conventional model
Doubled
• Metal noise reduced by a bumper on the impact part
of the switch valve
• Exhaust noise
reduced by a high-
noise reduction
silencer
Reduced
noise
Reduced by
Reduced by
13
13
dB
dB
(
A
)
compared with the conventional model
compared with the conventional model
compared with the conventional model
Reduced by
13 dB
(
A
)
• Mitigates condensation
caused by cooling during
exhaust expansion.
Integrated air-feeding tube with the
Integrated air-feeding tube with the
main tube
main tube
• Prevents operation failure due to foreign matter.
Built-in mesh filter at IN port
Built-in mesh filte
r at IN por
t
Improved reliability
Built-in mesh filter at IN port
Integrated air-feeding tube with the
main tube
Anti-condensation
Air-feeding tube
∗ Except VBA2쏔A, 4쏔A
VBA10A
VBA40A
VBA20A
NEW
NEW
Grease
retaining
groove
Floating structure
Mesh filter
Gauge port
Elbow silencer
VBA43A
VBA11A
VBA22A
VBA42A
Switching valve
Bumper
Features 1
