Datasheet

that of the conventional model
Doubled
Reduced by
13 dB
(
A
)
compared with the conventional model
Integrated air-feeding tube with the
main tube
Built-in mesh filte
r at IN por
t
Tank capacity (L)
Max. operating pressure (MPa)
Material
Model
VBAT10A
10
VBAT20A
20
Carbon steel
VBAT38A
38
1.02.0
VBAT05A
5
Body size
Set pressure
range
Operation
Pressure increase ratio
0.2 to 1.0 MPa
Handle-operated type
(Direct operation)
Air-operated type
(Remote operation)
Twice
Handle-operated type
(Direct operation)
2 to 4 times
0.2 to 1.6 MPa
(2.0 MPa)
0.2 to 1.0 MPa
VBA10A-02
(0.2 to 2.0 MPa)
VBA11A-02
VBA20A-03 VBA22A-03
VBA42A-04VBA43A-04
(0.2 to 1.6 MPa)
VBA40A-04
1/4"
3/8"
1/2"
0.2 to 2.0 MPa
P. 1
Air Tank Series
VBAT
P. 12
Perfect fit with a booster regulator
This is an air tank to which a booster regulator can be connected
compactly. It can be used alone as a tank. The pressure vessel law is
different from country to country, so as an air tank suitable to a
country needs to be confirmed.
Extensive product lineup
To meet a variety of usage environment and pressure specifications,
models are available in carbon steel (SS400), and in four sizes
ranging from 5 liters to 38 liters.
Features 2
