Technical data
Table Of Contents
- 1. INSTRUCTIONS FOR USE
- 2. SAFETY PRECAUTIONS
- 3. ENVIRONMENTAL RESPONSIBILITY
- 4. GET TO KNOW YOUR OVEN
- 5. AVAILABLE ACCESSORIES
- 6. FRONT PANEL
- 7. USING THE OVEN
- 7.2.1 Internal oven lights
- 7.2.2 Oven runners
- 7.2.3 Cooling system
- 7.6.1 Cooking with a preset temperature
- 7.6.2 Changing the preset temperature
- 7.7.1 Cooking timed with the timer
- 7.7.2 Semi-automatic cooking
- 7.7.3 Automatic cooking
- 7.7.4 Changing the preset temperature
- 1 P1: OFF / ON Activate or deactivate the child safety lock (); this function, after 2 minutes of operation without any actions by the user, locks all the functions and knobs; it is identified by the appearance of on DSP1. To temporarily deactivate l...
- 2 P2: OFF / ON Activate or deactivate the Show Room function; this function disables all the heating elements so that only the control panel works (to use the oven normally, set P2:OFF).
- 3 P3: OFF / ON Activate or deactivate the function that allows a maximum consumption of 2300 W.
- 7.8.1 Change the settings in the secondary menu
- 8. COOKING WITH THE OVEN
- 9. CLEANING AND MAINTENANCE
- 10. EXTRAORDINARY MAINTENANCE
- 11. INSTALLING THE APPLIANCE
Instructions for the user
55
6. FRONT PANEL
All the controls and indicator lights can be seen on the front panel. The tables
below describe the symbols used.
MULTIFUNCTIONPYROLYTIC
TIMER KNOB (on some models only)
This knob enables manual cooking or
the timer to be selected; the timer
switches off the oven automatically at
the end of cooking. If no cooking time is
selected, the timer knob must be
positioned on the symbol .
To set the cooking time, turn the knob clockwise to the “90” position and then set
the desired cooking time. Time is expressed in minutes (5 to 90). Adjustment is
progressive so that the time can also be set to any intermediate value between
these numbers. At the end of the programmed cooking time, a buzzer will sound
and switch off automatically after 4-5 seconds.
ELECTRIC OVEN THERMOSTAT KNOB (on some models only)
The cooking temperature is selected by
turning the knob clockwise to the
desired setting, between 50° and 250.
5
15
25
35
45
90
80
70
60
50
90
120
160200
220
250
ECO
0
1 2 3 4
5 6 4
ECO
ECO
P
P
0
