Instructions for the user
60
7.4 Operating modes (pyrolytic models)
This product is programmed to have 3 operating modes:
OFF setting: this is set when the knob PT2 is positioned on “0” and the current
time appears on the display.
ON setting: this is set when the selection knob PT2 is turned to any function
and the selected temperature appears on the display.
Stand-by setting: this is set when the selection knob PT2 is turned to any
function, a cooking time has been set and the current time appears on the
display.
7.5 First use (pyrolytic models)
On first use, or after a power failure, the oven's display (DSP1) will show a
flashing symbol. To be able to start any cooking function, the current
time must be set.
(For further information on setting or changing the current time see “7.8
Secondary menu (pyrolytic models)”).
7.6 Selecting functions (pyrolytic models)
To select a cooking function, turn PT2.
Then use PT1 to select the desired temperature.
7.6.1 Cooking with a preset temperature
Once the desired function has been selected, the oven will begin cooking at the
preset temperature. Cooking is preceded by a pre-heating phase (common to
all functions) which allows the oven to reach the cooking temperature more
quickly.
This phase is indicated by flashing on the display (DSP1). At the end of the
pre-heating phase, will remain constantly on to indicate that the food can
be placed inside the oven.
7.6.2 Changing the preset temperature
The preset temperature for each function can be changed to suit the user's
requirements.
At any time while cooking is in progress, turn PT1 in either direction to increase
or decrease the cooking temperature by 5 degrees at a time. PT1 can also be
held in the left or right position to increase or decrease the setting more quickly.
