Instructions for the installer
82
Removing the internal glass panel:
• Remove the internal glass panel by
pulling it upwards, following the
movement indicated by the arrows. Doing
this detaches the 4 pins attached to the
glass from their slots in the oven door.
Removing the middle glass panels:
(pyrolytic models)
• There are two middle glass panels in
pyrolytic models, attached using 4 small
locks. Remove the middle panes by lifting
them upwards.
(Multifunction models)
• Multifunction models have a single middle
panel. Remove the middle pane by lifting
it upwards.
Cleaning:
• Now it is possible to clean the external
glass panel and the panels removed
previously. Use absorbent kitchen roll. In
the case of stubborn dirt, wash with a
damp sponge and neutral detergent.
Replacing the glass panels:
• Replace the panes in the opposite order
to which they were removed.
• Reposition the internal glass panel, taking
care to centre and insert the 4 pins
attached to the glass into their slots in the
oven door by applying a slight pressure.
