8 SMOOTH CE3.0 ELLIPTICAL TRAINER
ASSEMBLY
STEP 1: Attach the Rear Roller Track Support Tube Cover and Transport Handle
(A) Attach the rear stabilizer cover to the roller track support tube (77) and secure with 4x M5*16(21) screws.
(B) Insert the transport handle through the top of rear stabilizer cover, then secure it with 2x M8*20(9) screws, 2
x M8*2.0T(15) spring washers and 2 x OD20*ID8.5*1.5T (8) curved washers.
(C) Tighten all bolts and screws now.
