16 SMOOTH CE3.0 ELLIPTICAL TRAINER
ASSEMBLY
STEP 9: Attach the Computer Monitor
(A) Connect the Computer wire Upper (16) to the computer monitor wire (A). Be certain the wires are facing the proper
direction and that the connectors lock in place.
(B) Connect the two heart rate wires (7) with the two heart rate wire (B). Be certain the wires are facing the proper
direction and that the connectors lock in place.
(C) Line up the four screw holes on the computer monitor(1) with the four holes on the computer post (10)
(D) Secure the computer monitor (1) to the computer post (10) with 4 x Computer screws (2)
(E) Tighten all bolts now
1
2
16
7
A
B
