5600 Watt Generator Operator’s Manual / Manual del Operario WARNING ADVERTENCIA Before using this product, read this manual and follow all Safety Rules and Operating Instructions. Antes de utilizar el producto, lea este manual y siga todas las Reglas de Seguridad e Instrucciones de Uso. Snapper™ is a licensed trademark of Briggs & Stratton Power Products. Snapper™ se usa abajo licencia a Briggs & Stratton Power Products.
Snapper 5600W Portable Generator SAVE THESE INSTRUCTIONS TABLE OF CONTENTS SAFETY RULES Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4 Know Your Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Snapper 5600W Portable Generator WARNING WARNING Running generator gives off carbon monoxide, an odorless, colorless, poison gas. Breathing carbon monoxide can cause nausea, fainting or death. Fuel and its vapors are extremely flammable and explosive. Fire or explosion can cause severe burns or death. • Operate generator ONLY outdoors. WHEN ADDING OR DRAINING FUEL • Turn generator OFF and let it cool at least 2 minutes before removing fuel cap. Loosen cap slowly to relieve pressure in tank.
Snapper 5600W Portable Generator CAUTION WARNING Excessively high operating speeds increase risk of injury and damage to generator. Excessively low speeds impose a heavy load. Unintentional sparking can result in fire or electric shock. • DO NOT tamper with governed speed. Generator supplies correct rated frequency and voltage when running at governed speed. • DO NOT modify generator in any way.
Snapper 5600W Portable Generator KNOW YOUR GENERATOR Read this Operator’s Manual and safety rules before operating your generator. Compare the illustrations with your generator, to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference.
Snapper 5600W Portable Generator ASSEMBLY • Wheel kit If any parts are missing or damaged, call the generator helpline at 1-800-317-7833. Your generator requires some assembly and is ready for use after it has been properly serviced with the recommended oil and fuel. If you have any problems with the assembly of your generator, please call the generator helpline at 1-800-317-7833. If calling for assistance, please have the model, revision, and serial number from the data tag available.
Snapper 5600W Portable Generator NOTE: Check oil often during engine break–in. Refer to engine operator’s manual for recommendations. CAUTION E-rings can cause eye injury. E-rings can spring back and become airborne when installing or removing. NOTE: The generator assembly rotates on a prelubricated and sealed ball bearing that requires no additional lubrication for the life of the bearing. • Always wear eye protection when installing/removing e-rings. 6.
Snapper 5600W Portable Generator USING THE GENERATOR Generator Location Generator Clearance System Ground WARNING The generator has a system ground that connects the generator frame components to the ground terminals on the AC output receptacles.The system ground is connected to the AC neutral wire (the neutral is bonded to the generator frame). Exhaust heat/gases can ignite combustibles, structures or damage fuel tank causing a fire. • Keep at least 5 ft.
Snapper 5600W Portable Generator OPERATING THE GENERATOR WARNING Running engines produce heat.Temperature of muffler and nearby areas can reach or exceed 150°F (65°C). Severe burns can occur on contact. Exhaust heat/gases can ignite combustibles, structures or damage fuel tank causing a fire. Starting the Engine Disconnect all electrical loads from the generator. Use the following start instructions: 1. • DO NOT touch hot surfaces and avoid hot exhaust gases. • Allow equipment to cool before touching.
Snapper 5600W Portable Generator Stopping the Engine 1. Turn OFF and unplug all electrical loads from generator panel receptacles. NEVER start or stop engine with electrical devices plugged in and turned ON. 2. Let engine run at no-load for several minutes to stabilize internal temperatures of engine and generator. 3. Turn engine off according to instructions given in the engine operator’s manual. 4. Move fuel valve to “Off” position.
Snapper 5600W Portable Generator DON'T OVERLOAD GENERATOR 4. Plug in and turn on the next load. 5. Again, permit the generator to stabilize. 6. Repeat steps 4 and 5 for each additional load. NEVER add more loads than the generator capacity.Take special care to consider surge loads in generator capacity, as described above. Capacity You must make sure your generator can supply enough rated (running) and surge (starting) watts for the items you will power at the same time. Follow these simple steps: 1.
Snapper 5600W Portable Generator SPECIFICATIONS Generator Maintenance Starting Watts . . . . . . . . . . . . . . . . . . . . . . . . .8,600 watts Wattage . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5,600 watts Power Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.0 Rated AC Load Current: At 120 Volts . . . . . . . . . . . . . . . . . . . . . . . . .46.6 Amps At 240 Volts . . . . . . . . . . . . . . . . . . . . . . . . .23.3 Amps Phase . . . . . . . . . . . . . . . . .
Snapper 5600W Portable Generator STORAGE Engine Storage See engine operator’s manual for instructions. The generator should be started at least once every seven days and allowed to run at least 30 minutes. If this cannot be done and you must store the unit for more than 30 days, use the following guidelines to prepare it for storage. Other Storage Tips • To prevent gum from forming in fuel system or on essential carburetor parts, add fuel stabilizer into fuel tank and fill with fresh fuel.
Snapper 5600W Portable Generator TROUBLESHOOTING Problem No AC output is available, but generator is running. Generator runs good at no-load but "bogs" down" when loads are connected. Generator will not start; or starts and runs rough. Generator shuts down during operation. Generator lacks power. Cause Correction 1. One of the circuit breakers is open. 1. Reset circuit breaker. 2. Fault in generator. 2. Contact Authorized service facility. 3. Poor connection or defective cord 3. set.
SNAPPER™ OWNER WARRANTY POLICY Effective August 1, 2004 LIMITED WARRANTY “Snapper™ is a licensed trademark of Briggs & Stratton Power Products. Briggs & Stratton Power Products will repair or replace, free of charge, any part, or parts of the equipment** that are defective in material or workmanship or both.Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser.
Generador Portátil de 5600W Snapper CONSERVE ESTAS INSTRUCCIONES TABLA DE CONTENIDOS REGLAS DE SEGURIDAD Reglas De Seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-18 Conozca Su Generador . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Montaje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21 Operación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-25 Mantenimiento . . . . . . . . .
Generador Portátil de 5600W Snapper ADVERTENCIA ADVERTENCIA Al generador funcionar, se produce monóxido de carbono, un gas inodoro y venenoso. El respirar el monóxido de carbono, producirá náusea, desmayo o la muerte. La combustible y sus vapores son extremadamente inflamables y explosivos. El fuego o una explosión pueden causar quemaduras severas e inclusive la muerte. • Opere el generador SOLAMENTE al aire libre.
Generador Portátil de 5600W Snapper PRECAUCIÓN ADVERTENCIA Las velocidades de operación en exceso, aumentan los riesgos de heridas y daños al generador. Las velocidades bajan en exceso, imponen una carga muy pesada. Chispear involuntario puede tener como resultado el fuego o el golpe eléctrico. CUANDO AJUSTE O HAGA REPARACIONES A SU GENERADOR • NO cambie ninguna velocidad determinada. El generador suministra una frecuencia y un voltaje calificado cuando funciona a una velocidad determinada.
Generador Portátil de 5600W Snapper CONOZCA SU GENERADOR Lea este Manual del Operario y las reglas de seguridad antes de operar su generador. Compare las ilustraciones con su Generador para familiarizarse con las ubicaciones de los diferentes controles y ajustes. Conserve este manual para referencias futuras.
Generador Portátil de 5600W Snapper MONTAJE • Manual del Operario de Motor Su generador requiere de ciertos procedimientos de montaje y solo estará listo para ser utilizado después de haberle suministrado servicio con el combustible y aceite recomendados. • Juego de Ruedas Si usted tiene problemas con el montaje de su generador, por favor llame a la línea de ayuda para generadores al 1-800-317-7833.
Generador Portátil de 5600W Snapper NOTA: Verifique el aceite del motor de manera frecuente cuando éste se esfuerce demasiado. Consulte el manual del operario del motor para conocer cuáles son las recomendaciones al respecto. PRECAUCIÓN Las anillas en “e” pueden provocar lesiones oculares. Las anillas en “e” pueden salir disparadas durante el montaje o el desmontaje.
Generador Portátil de 5600W Snapper USO DEL GENERADOR Ubicación del Generador Espacio Libre Alrededor del Generador Tierra del Sistema ADVERTENCIA El generador dispone de una conexión a tierra del sistema que conecta los componentes del bastidor a los terminales de tierra de los enchufes hembra de salida de CA. La tierra del sistema está conectada al cable de CA neutro que, a su vez, está conectado al bastidor del generador (vea “Descripión del Equipo”).
Generador Portátil de 5600W Snapper OPERANDO EL GENERADOR ADVERTENCIA Los motores al funcionar producen calor. La temperatura del silenciador y de las áreas cercanas puede alcanzar o pasar los 150ºF (65ºC). Quemaduras severas pueden ocurrir al hacer contacto. Los gases y el calor de escape pueden inflamar los materiales combustibles y las estructuras o dañar el depósito de combustible y provocar un incendio. Encienda el Motor Desconecte todas las cargas eléctricas del generador.
Generador Portátil de 5600W Snapper Parado Del Motor 1. Gire lejos y desconecte todas las cargas eléctricas de los tomaco-rrientes del panel del generador. NUNCA de arranque o detenga el motor con todos los dispositivos eléctricos conectados y encendidos. 2. Deje que el motor funcione sin cargas por algunos minutos para estabilizar las temperaturas internas del motor y el generador. 3. Pare el motor tal y como se explica en el manual del operario del motor. 4. Cierre la válvula del combustible.
Generador Portátil de 5600W Snapper NO SOBRECARGUE GENERADOR 4. 5. 6. Conecte y encienda la próxima carga. De nuevo, permita que el generador se estabilice. Repita los pasos 4 y 5 para cada carga adicional que usted tenga. NUNCA añada más cargas sobre la capacidad del generador. Tome una atención especial en considerar las cargas de corriente según la capacidad del generador, como se describe arriba.
Generador Portátil de 5600W Snapper NOTA: NO recomendamos el uso de mangueras de jardín para limpiar el generador. El agua podría introducirse en el sistema de combustible del motor y causar problemas. Además, si el agua se introduce al generador a través de las ranuras para aire de enfriamiento, algo del agua quedará retenida en los espacios vacíos y grietas del aislamiento del devanado del estator y rotor.
Generador Portátil de 5600W Snapper ALMACENAMIENTO Almacenando el Motor El generador deberá ser encendido al menos una vez cada siete días y deberá dejarlo funcionar al menos durante 30 minutos. Si no puede hacer esto y debe almacenar la unidad por más de 30 días, siga las siguientes instrucciones para preparar su unidad para almacenamiento. Consulte el manual del operario del motor para las instrucciones de cómo preparar adecuadamente el motor para su almacenamiento.
POLÍTICA PARA EL PROPIETARIO DE EQUIPOS SNAPPER™ Efectiva desde el 1 ro de Agosto, 2004 GARANTÍA LIMITADA "Snapper™ se usa abajo licencia a Briggs & Stratton Power Products. Briggs & Stratton Power Products reparará o sustituirá sin cargo alguno cualquier componente del equipo** que presente defectos de materiales y/o mano de obra. Los gastos de transporte de la producto enviadas para reparar o sustituir conforme a los términos de esta garantía correrán a cargo del comprador.
