Admin and Installation Guide M700, M300 Firmware Update
Fig. 3
Parameter descriptions for Add extension and Edit Extension subpages:
Setting Description
Line name As required/desired. Specifies the line name for this extension on the
handset. Used when user must select a line for outgoing calls.
Handset Select New Handset or one of the available Handset IDXs
Extension Extension number or SIP username, as configured in PBX or on SIP
server.
Authentication User Name As required by PBX or VoIP provider
Authentication Password As required by PBX or VoIP provider
Display Name As required or desired
PIN
This is the PIN for accessing the mailbox, if required by PBX or VoIP
provider and if a mailbox is available.
Note: This PIN is not to be confused with either the access code for
registering the handset at the base station or the PIN for resetting the
handset to factory values or for deregistering it from the base station.
Mailbox Name If mailbox available on PBX or provided by VoIP provider. If no mailbox
name is set, same as mailbox number.
Mailbox Number If mailbox available on PBX or provided by VoIP provider. Often the same
as the extension number.
Accessing mailbox: Long-press key 1 on handset to connect to mailbox.
Server Select server from drop-down menu
Call waiting feature Turn call waiting on/o. Default: Enabled (on).
Broadsoft Feature Event Package On/o. Applicable only to Broadsoft applications. If enabled, the
extension subscribes to the Broadsoft Application Server Feature Event
Package and is ready to receive SIP Notify with status for the Broadsoft
server services "do not disturb (DND)" and "call forwarding" (always,
busy, no answer) .
