Model Number: SG-TTW-14HC Electronic Through the Wall Air Conditioner Operating Instructions V.
Thank you for choosing a Soleus Air powered by Gree Air Conditioner. This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new air conditioner. For your own records, please attach a copy of your sales receipt to this manual.
ELECTRICAL REQUIREMENTS The electrical ratings for your air conditioner are listed on the model and serial number label located on the front left side of the unit (when facing the front). Specific electrical requirements are listed in the chart below. Follow the requirements below for the type of plug on the power supply cord. Power Supply Cord Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove the ground prong. Do not use an adapter Do not use an extension cord.
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this air conditioner FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Read product labels for flammability and other warnings.
SPECIFICATIONS x Noise level is measured at a distance of 3.28 ft away from the front of the unit in cooling mode. x Power consumption is measured when the fan runs at the highest speed setting. x These specifications are for reference only. For actual data, please refer to the rating label on the unit.
OPERATING YOUR AIR CONDITIONER Before you start using your air conditioner, please familiarize yourself with the control panel and remote control the functions of each. This air conditioner can be controlled by the control panel (touch pad) or the included remote control.
Air Conditioner Features(continued) Note: Be sure that there are no obstructions between receiver and remote controller; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. Signal transmitter SLEEP SLEEP button ● Remote control FAN Press this button, Sleep On and Sleep Off can be selected. After powered on,Sleep Off is defaulted.
Air Conditioner Features(continued) Notice: This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model dosen't have, if press the corresponding button on the remote controller that the unit will keep the original running status. TIMER TIMER button ● By pressing this key under switch-off state, you may set the time for auto switch-on. The range of setting is 0.5 ~ 24 hours.
Air Conditioner Features(continued) Guide for operation- General operation 1. After powered on, press ON/OFF button, the unit will start to run.(Note: When it is powered off, the guide louver of main unit will close automatically.) 2. Press MODE button, select desired running mode, or press COOL or HEAT mode to enter into the corresponding operation directly. 3. Pressing + or - button, to set the desired temperature. (It is unnecessary to set the temp. at AUTO mode.) 4.
Air Conditioner Features(continued) YOU WILL SEE : TO TURN UNIT ON: DO THIS: PRESS ON/OFF BUTTON TO CHANGE TEMPERATURE SETTING: YOU WILL SEE: DO THIS: PRESS TO RAISE PRESS TO LOWER Note: Tap or hold either up(^) or down(v) button until the desired temperature is seen on display. This temperature will be automatically maintained anywhere between 61F (16° C) and 86F (30° C) for both cooling and heating modes. If you want the display to read the actual room temperature, "Select the fan only mode" .
Air Conditioner Features(continued) TO OPERATE ON FAN ONLY: LIGHT ON YOU WILL SEE: DO THIS: PRESS MODE BUTTON CHOOSE FAN ONLY Note: Use this function only when cooling is not desired, such as for room air circulation. You can choose any fan speed you prefer,EXCEPT AUTO FAN. During this function, the display will show the actual current temperature, not the set temperature as in the cooling mode.
Air Conditioner Features(continued) YOU WILL SEE : HEATING FEATURE (on some models) : DO THIS: PRESS MODE BUTTON SELECT HEAT Note: This feature can be used with any combination of FAN Speeds, Timer, or Sleep Modes. When in the “Heat” Mode, the fan will run continuously while heat is needed. The temperature will automatically be maintained anywhere between 61°F (16°C) and 86°F (30°C). When the room set temperature is satisfied, the fan will cycle off and on to circulate and sample the room air.
CARE AND CLEANING Clean your air conditioner to keep it looking new and to minimize dust build up. Cabinet Cleaning To clean the air conditioner cabinet: x Unplug the air conditioner to prevent shock or a fire hazard. The cabinet and front panel of the air conditioner may be dusted with an oilfree cloth or washed with a cloth dampened in a solution of warm water and mild liquid soap. Rinse thoroughly with a damp cloth and wipe dry.
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES SOLUTIONS The Air Conditioner will not start The air conditioner is unplugged x Make sure the air conditioner is plug is pushed completely into the outlet The fuse is blown/circuit breaker is tripped. x Check the house fuse/circuit breaker box and replace the fuse or reset the breaker. Power Failure x The unit will automatically re-start when power is restored. There is a protective time delay (approx.
TROUBLESHOOTING (CONT.) PROBLEM POSSIBLE CAUSES SOLUTIONS Water is dripping outside Hot and Humid weather. x This is normal Water is dripping inside the room The air conditioner is not correctly tilted outside. x For proper water drainage, make sure the air conditioner is slightly tilted downward from the front of the unit to the rear. Water collects in the base pan Moisture removed from the air is draining into the base pan.
Warranty Soleus International Inc. warrants the accompanying Soleus Air Air Conditioner to be free of defects in material and workmanship for the applications specified in its operation instruction for the period of parts specified below. 5 YEARS FOR COMPRESSOR 1 YEAR FOR OTHER COMPONENTS This warranty shall not apply to broken or marred cabinets, accessories, knobs, filters or routine maintenance.
