Thank you for choosing a Soleus Air powered by Gree Air Conditioner. This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new air conditioner. For your own records, please attach a copy of your sales receipt to this manual.
ELECTRICAL REQUIREMENTS The electrical ratings for your air conditioner are listed on the model and serial number label located on the front left side of the unit (when facing the front). Specific electrical requirements are listed in the chart below. Follow the requirements below for the type of plug on the power supply cord. Wiring Requirements Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove the ground prong. Do not use an adapter Do not use an extension cord.
PACKING LIST • Window Air Conditioner • Top Mounting Rail • Top Mounting Rail Seal Strip • 3/8” Screw for Top Mounting Rail (4) • Accordion Panels (2) • Sash Lock • Window Sash Seal • 3/4” Screw for Sash Lock and Accordion Panels (6) • Foam Top Window Gasket • Owner’s Manual SPECIFICATIONS • Noise level is measured at a distance of 3.28 ft away from the front of the unit in cooling mode. • Power consumption is measured when the fan runs at the highest speed setting.
INSTALLATION & ASSEMBLY INSTRUCTIONS Some assembly is required for your new air conditioner. Please read and follow these instructions carefully. 1. This air conditioner is designed to be installed in a standard double-hung window with a window width between 23” and 38” (584 mm - 965 mm). 2. The air conditioner can be installed without the accordion panels to fit in a narrow window opening. See the window dimensions. 3. The Lower Sash (the lower part of the window that moves up and down) must allow for 12.
ASSEMBLY & INSTALLATION (CONT.) Accordion Panel Installation Storm Window Requirements Now that you have installed the top rail, you can now install A storm window frame will not allow the air conditioner to tilt properly which in turn will keep it from draining properly. the accordion panels on each side. To adjust for this, attach a board or piece of wood to the sill. The board or wood piece should have a depth of at 1. Place the air conditioner on a hard flat surface. least 1 1/2”.
ASSEMBLY & INSTALLATION (CONT.) Frame Lock, Sash Lock, and Foam Seal Installation FIG.11 MOUNTING HARDWARE 3/4” Screws Sash Lock 2. To secure the lower sash into place, use the sash lock and a 3/4” screw as shown below (See FIG. 11) 6 1 Tools Needed: Phillips Screw Driver Drill (if plot holes are needed) 3. For added insulation, cut the supplied insulation foam to the width of the window. Insert the foam between the window sashes to prevent air and objects from getting into the room. (See FIG.
USING YOUR AIR CONDITIONER Operating Your Air Conditioner Manual Control Panel 1. Power: Turn on the unit by rotating the MODE dial to the desired setting. 2. Cooling Mode: For maximum cooling set the MODE dial to “HIGH COOL”. In HIGH COOL mode, the fan will automatically go to high. This will help circulate the cool air throughout the room. The fan will operate on low in “LOW COOL” mode 3. Fan Mode: For fan only modes, choose either HIGH FAN or LOW FAN.
CARE AND CLEANING Clean your air conditioner to keep it looking new and to minimize dust build up. Cabinet Cleaning To clean the air conditioner cabinet: • Air Filter Cleaning The air filter should be checked at least once every month to see if it needs cleaning. Trapped particles and dust can build up in the filter and may decrease airflow as well as cause the cooling coils to accumulate frost. To clean the air • filter: 1.
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES SOLUTIONS The Air Conditioner will not start The air conditioner is unplugged • Make sure the air conditioner is plug is pushed completely into the outlet The fuse is blown/circuit breaker is tripped. • Check the house fuse/circuit breaker box and replace the fuse or reset the breaker. Power Failure • The unit will automatically re-start when power is restored. There is a protective time delay (approx.
TROUBLESHOOTING (CONT.) PROBLEM POSSIBLE CAUSES SOLUTIONS Water is dripping outside Hot and Humid weather. • This is normal Water is dripping inside the room The air conditioner is not correctly tilted outside. • For proper water drainage, make sure the air conditioner is slightly tilted downward from the front of the unit to the rear. Water collects in the base pan Moisture removed from the air is draining into the base pan.
Warranty Soleus International Inc. warrants the accompanying Soleus Air Air Conditioner to be free of defects in material and workmanship for the applications specified in its operation instruction for the period of parts specified below. 5 YEARS FOR COMPRESSOR 1 YEAR FOR OTHER COMPONENTS This warranty shall not apply to broken or marred cabinets, accessories, knobs, filters or routine maintenance.
