Data Sheet

Overview

Designed to ﬁt any new construction or retro-ﬁt application

in standard 3 1/2” deep wall cavities, the VPSUB delivers

cabinet-level performance in a discreet in-wall form factor.

Key Features

Aesthetics

• Sleek, low proﬁle design consistent with Sonance

Visual Performance Series

Performance

• Massive re-designed motor structure

• Dual Spider Technology (DST) for up to +/- 13mm of

controlled linear excursion

• 4 1/2” (115mm) precision-aligned voice coil with 1 1/2”

(38mm) winding height

• 1.4 lbs (.64kg) N38SH Neodymium magnet

• Custom-tuned DSP settings when paired with a Sonance

DSP ampliﬁer (sold separately)

Installation

• Designed to ﬁt into a standard 3 1/2” wall cavity with 16”

on-center stud conﬁguration

• Simpliﬁed single-step grille painting process

• Spring-loaded speaker wire terminals to accept standard

wire or pin connector

VPSUB

IN-WALL SUBWOOFER

VISUAL PERFORMANCE

VPSUB

VPSUB Grille

Speaker Terminal

PAGE 1
VISUAL PERFORMANCE IN-WALL SUBWOOFER VPSUB Overview Designed to fit any new construction or retro-fit application in standard 3 1/2” deep wall cavities, the VPSUB delivers cabinet-level performance in a discreet in-wall form factor.
PAGE 2
VPSUB Dimensions Width: 15” (381mm) Height: 15” (381mm) Depth: 3 7/8” (98mm) Cut Out Width: 12 3/4” (324mm) Cut Out Height: 12 3/4” (324mm) Cut Out Height Height Width Depth Cut Out Width Specifications SKU: 93353 Unit of Measure: Each Woofer: 10” (254mm) laminated carbon fiber cone with a rubber surround Frequency Response: 34Hz - 250Hz ±3dB Impedance: 8 Ohms nominal Sensitivity: 90dB SPL (2.
