2.1 Computer Speaker

Summary of content (6 pages)

PAGE 1
2.
PAGE 2
Catalog 1. Catalog.................................................................................1 2. Safety Information..............................................................2-3 3. Front Panel - Controls and Functions....................................4 4. Back panel - Controls and Functions.....................................5 5. System Connection Instructions............................................6 6. Operation Instruction.........................................................7-8 7.
PAGE 3
Specifications Safety Information Power Supply.............................................................. 240V~ 50Hz Power Consumption................................................................ 90W Input Sensitivity(Subwoofer).................................... 300mV±50mV Input Sensitivity(Surround)...................................... 500mV±50mV S/N (A Weight)..................................................................... ±75dB Main sound Power Output (RMS)................................
PAGE 4
Operating Instruction Safety Information 3.Do not install the equipment in a dusty, damp or poorly ventilated place. D. MUTE Selection 1. Press the MUTE button on the left for a voice . 4.To prevent damage to the equipment,please unplug from the power outlet if not in use. 4 2. Press the MUTE button on the right for silent . 5.To unplug the equipment,always handle to power cord using the plug.Do not pull out the plug by tugging the cord. 6.
PAGE 5
Operating Instruction Front Panel - Controls And Functions A. Switching On/Off 1. Press the POWER switch button to "ON" on the back panel to switch on the unit to enter the normal status. 2. To switch the unit off, press the POWER switch button to "OFF" on the back panel. Note: If you do not use the unit in long time, please pull out the AC power plug. B. Volume Selection 1. Twisting the "VOL+" knob on the front panel to maximize the sound output. 2.
PAGE 6
System Connection Instructions Back Panel - Controls And Functions 1 TV To Stereo Output 2 Video In 3 4 5 RCA Cable 240V~ 50Hz 6 7 1.Right Channel Input Jack. 2.Left Channel Input Jack. 3.Control Jack. Woofer Rear-L Front-L Center Rear-R Front-R Video 4.Right Speaker Output. 5. Left Speaker Output. Audio Out Video Out Scart out 6.AC Power cable . 7.POWER ON/OFF Switch. 5 Woofer Rear-L Front-L Center Rear-R Front-R Manufactured under license from Dolby Laboratories.
