L42V12A - AU
1 2-5 6 6 6 7-8 7 8 9-10 9 11-13 11 11 12 12 13 13 14 14 Menu Operation Guide Source Selection Vol+/Vol-(Volume control) Menu operation CHANNEL PICTURE SOUND TIME OPTION LOCK PVR Function Media play Function 15-17 15 16 16 17-18 19 19 20 21 21 22-23 24-28 29 31
Screws: ST4x14F(x7, Black)
Press this button to turn the unit on when it is in standby mode. Press this button once more to put it to standby mode.
8 2 3 4 .
/ Press to return to previous chapter or track.
-10-
-13-
-14-
1.Press SOURCE button to display the input source list. 2.Press YPbPr / or SOURCE button to select the input source you want to. 3.Press “OK” button to enter the input source. 4.Press “EXIT” to quit. EPG: It is only available in DTV mode.
Schedule: Press yellow key to browse the program information saved in the schedule list, and press yellow key or exit to return. Schedule List 09:33 25th Dec Delete Time Date Programme Title Channel Name 10:00 Sun, 25 Dec SP-THE SINGING CHRISTMAS TREE 7 7 Digital INFO: Press green key to view the details of the focused channel. 25 Dec 2005 09:00-10:00 A religious program. WS Remind: Press blue key to add a program needs to be reminded, and it will be switched on time.
CHANNEL MENU Press MENU button to enter the CHANNEL page as follows: CHANNEL CHANNEL Auto Tuning DTV Manual Tuning ATV Manual Tuning Programme Edit Signal Information Back Select A. Auto Tuning 1.Auto Tuning will be highlighted on entering this screen. Press OK button to continue. 2.Press / to select country, Press OK button to continue. 3.Press / to select your location and press OK to continue. Then use / to choose the tuning type. 4.Press OK to start auto search.
Programme Edit Press / to select Program Edit, then press OK button to enter sub-menu. Progr am me Edi t 7 7 Di gi tal DTV 70 7 HD Di gi tal DTV 71 7 Di gi tal 1 DTV 72 7 Di gi tal 2 DTV 73 7 Di gi tal 3 DTV 77 7 Gui de DTV 1 C-02 ATV 2 C-04 ATV 3 S-0 4 ATV ATV 4 C-08 Delet e Rename Move Skip FAV 1. Press red button to delete the selected program. 2. Press yellow button to change program order. Selected channel can be moved by using / , then press“OK” for confirm. 3.
PICTURE MENU 1. Press MENU button to bring up the main menu. 2. Then press / to enter PICTURE page, it will highlight the first option, press OK button to enter. 3. Picture Mode: Press / to adjust the mode by Standard, Dynamic, Mild, User. Contrast, Brightness, Color, Sharpness can be adjusted only under user mode, Press “Menu” to return to the main menu. 4. Color Temperature: Press / button to select Cool, Standard, Warm and User. You can adjust the Red, Green and Blue in User mode. 5.
TIME MENU Press MENU to display the main menu. Use / to enter TIME page, it will highlight the first option. TIME TIME Off Time On Time Clock 02/Jun 15:55 Time Zone New South Wales/ACT Auto Sleep Back Select Off Time On Time TIME TIME Off Time Every Day Hour 0 Minute 0 Mode Select Once Hour 12 Minute 1 Source AV Volume 30 Back Select - Press OK button to enter submenu. Press / to adjust. Time Zone Press / Back Select - Press / to select On Time, then press OK button to enter the sub-menu.
OPTION MENU Press MENU to display the main menu. Press / to enter OPTION page, it will highlight the first option. OPTION OPTION Back OPTION OSD Language English PVR File System OSD Time Out OSD Transparency Restore Factory Default Back Back OPTION OSD Time Out Off OSD Transparency Restore Factory Default Version Info Blue Screen Select Back Select OSD Language: Only English can be selected in the function.
PVR File System PVR function is only available for DTV, includes Record, Timeshift and Playback functions. Record includes in time record and preserve record. In time record can be worked through REC key immediately, and preserve record needs to preserve beforehand. Record and Playback can be done at the same time. Timeshift is another function for both recording and playing. The following will explain in details.
Then Press OK button to start format the disk, then a warning with “All data will be lost” will be displayed to remind the user to choose Start or EXIT. Press button to start, button to exit. Format disk Warning! All data will be lost.
PVR Recorder Schedule Press yellow button on the remote control to display schedule list. Schedule List 09:33 25th Dec Delete Time Date Programme Title Channel Name 10:00 Sun, 25 Dec SP-THE SINGING CHRISTMAS TREE 7 7 Digital Timeshift Press TSR button to delay the process of program broadcasting in DTV mode. 20:13 Time Shift A B [00:00:03/00:00:00] MEDIA Menu Note: Before operating MEDIA menu, plug in USB device, then press SOURCE button to set the Input Source.
When highlighting the option you select, picture can be previewed and information of the picture will appear. Press ◄/► button to select the file you want in the file selecting menu, then press button to display the picture. MEDIA\Photo\JPEG 1/11 Resolution: Return Up Folder 000111.jpg QXQ 06.mp3 0521hangmu09.jpg Size: 1280x800 music 199 KBytes Date: ---- / -- / -- Time: -- : -- : -- 10024616c.mp3 0521hangmul3.jpg 0521hangmu15.jpg Sub Menu 08_gC1WIvNHu1UZ_0..
MUSIC Menu Press ◄/► button to select MUSIC in the main menu, then press OK button to enter. Press EXIT button to quit the menu. Press ◄/► button to select drive disk, then press OK button to enter. Press ◄/► button to select Return option to go back to the previous menu. When highlighting the option you selected, music can be previewed and information of the music. 1/15 C: MEDIA Music MP3 Return Up Folder QXQ Album: music Title: Blt Rate: 128K Artist: Sampling: 44K Year: 03.mp3 1139153940.
MOVIE Menu Press / button to select MOVIE in the main menu, then press OK button to enter. Press EXIT button to quit the menu. Press / button to select the drive disk you want, then press OK button to enter. Press / button to select Return option to go back to previous menu. When highlighting the option you selected, movie can be previewed and information will appear.
TEXT Menu Press / button to select TEXT in the main menu, then press OK button to enter. Press EXIT button to quit the menu. Press / button to select the drive disk you want, then press OK button to enter. Press / button to select Return option to go back to previous menu. When highlighting the option you selected, text can be previewed and information will appear. Press button to view the selected text. 1/1 MEDIA\Text Return chinese txt.txt This book by the www.wmtxt.
-29-
-30-
8W+8W 1240(L)x175(W)x770(H)mm -31-
MD120727-01
