L60U11A - AU 60" FullHD LCDTV MD110802-01 with Touch Screen
9-10 11-16 Connecting Connecting HDMI signals Connecting S-Video signals Connecting Composite Video signals Connecting COAXIAL signals Menu Operation Guide Source Selection Vol+/Vol-(Volume control) Menu operation CHANNEL PICTURE SOUND TIME OPTION LOCK PVR Function Media play Function 17-18 19-23 19-20 24-25 26-30 1. Software Introduction ..........................................................................31 2. Software Installation ..............................................................
Main Unit Instruction Manual VGA VGA AUDIO Installation Disc Touch Pen USB
13 12 Navigation keys your preference. In DTV mode, press OK to display Channel List. USB and program recording. None. COMPONENT1/ COMPONENT2 Coaxial Digital Audio output for Digital Amplifier. 12 POWER 13 TOUCH SCREEN USB-A Press to power on or off the unit. Connect to PC with USB line. A-B Press to select A-set, AB-set, None for repeat function. GOTO Press to select all under Media mode.
Y1 Pb1 Pr1
Connect USB Device directly to the unit.
1.Press SOURCE button to display the input source list. 2.Press / or SOURCE button to select the input source you want to. YPbPr 1 YPbPr 2 3.Press “OK” button to enter the input source. 4.Press “EXIT” to quit. EPG: It is only available in DTV mode.
Schedule: Press yellow key to browse the program information saved in the schedule list, and press yellow key or exit to return. Schedule List 09:33 25th Dec Delete Programme Title Channel Name Sun, 25 Dec SP-THE SINGING CHRISTMAS TREE 7 7 Digital CHANNEL INFO：Press green key to view the details of the focused channel.
Programme Edit Press / to select Program Edit, then press OK button to enter sub-menu. Programme Edit 7 7 Digital DTV 70 7 HD Digital DTV 71 7 Digital 1 DTV 72 7 Digital 2 DTV 73 7 Digital 3 DTV 77 7 Guide DTV 1 C-02 ATV 2 C-04 ATV 3 S-04 ATV ATV 4 C-08 Delete Rename Move Skip FAV 1. Press red button to delete the selected program. 2. Press yellow button to change program order. Selected channel can be moved by using / , then press“OK” for confirm. 3.
OPTION MENU Press MENU to display the main menu. Press / to enter OPTION page, it will highlight the first option. TIME MENU TIME OPTION TIME OPTION Press MENU to display the main menu. Use / to enter TIME page, it will highlight the first option.
PVR Function PVR Function PVR File System PVR function is only available for DTV, includes Record, Timeshift and Playback functions. Record includes in time record and preserve record. In time record can be worked through REC key immediately, and preserve record needs to preserve beforehand. Record and Playback can be done at the same time. Timeshift is another function for both recording and playing. The following will explain in details.
MEDIA\Photo\JPEG 1/11 Resolution: Return Up Folder 000111.jpg 0521hangmu09.jpg QXQ 06.mp3 ---- / -- / -- Time: -- : -- : -- 10024616c.mp3 0521hangmul3.jpg 0521hangmu15.jpg Sub Menu 08_gC1WIvNHu1UZ_0.. Select/Unselect All C:\MEDIA\Photo\BMP Return 1/2 Up Folder 1600x1200b.mp 21312.bmp GRAY2.bmp untitled.bmp 1024x768_bmp.bmp Return 1440x900.bmp DTVLOGO_NESX.bmp untitled1.bmp Sub Menu C:\MEDIA GRAY1.bmp untitled123.
C:\MEDIA\Movie\mkv 1/15 C: MEDIA Music MP3 Return Up Folder QXQ Album: music 1/2 Return Resolution: 1920 x 1080 Audio Track: 1/2 Subtitle: OFF Program: -/0 Size: 519585 KBytes 720p_chd-mr&mrs-smi_ Title: Blt Rate: 128K BigBuckBunny_108-[Divx7]_AAC5.1_A_ Artist: Sampling: 44K Year: 03.mp3 06.mp3 10024616c.mp3 Slze: 3924 KBytes Paranormal_Activity_[- Samsung.Demo.Oceani_ Shutter_Island_[Divx_-[MV].Hotcha-.PartyGi - Sub Menu 1139153940.mp3 1174270662.
1/1 MEDIA\Text Return chinese txt.txt This book by the www.wmtxt.com(unkno wn txt novel download site) for you to or ganize production Download free novels more exciting,more complete version of the nover e-book dow nload please visit www.wmtxt.com Size: chapter English txt.
Software Unload Software Installation (3) Select destination folder. You can change it based on your own requirement. Then click “Next”: 3. Software Unload If Fitouch program is running, please exit it first.
Software Application Software Application 4. Software Application 4.3.1. Basic Mode Calibrating 4.1. Running (1) The software will run automatically on boot-up under the default mode, you can find the tray-liked icon on the bottom right of the desktop. (2) If you closed this software by accident, you can find "Free Interactive Technology" through entering"Start"->"All prgrams", and then select" Fitouch" to run the program.
Software Application Software Application 4.3.3. Senior Mode Calibrating 4.4.1. Info It is Senior Calibrating when “Senior” is selected. In this mode, user can calibrate the screen flexibly based on your own demands. Should you have any problem when calibrating the screen in this mode, please contact our company for technical support. “Basic” shows information of the connected touch screen.
Software Application Software Application 4.4.2. Configuration TS02R02B021B 00003513 Upgrade Click “Upgrade” and open the authorization document, then it can upgrade. (The correspond authorization document is in the box.) Configuration supplies Service Parameters for user to select. “Service Parameter”（Right key part only can be adjusted in Single point mode ) Default setting is recommended in the configuration of service parameter. User can modify it if necessary.
FAQ Software Application If situation like breakpoint, line jump or environment change occurs, please first make sure there are no other debris and distortion and then select “Write Init”. User can restart the device through “Restart” according to practical demands. “Check All” provides the function of inspecting the parameter value of every pair of light tubes, by which determine the working state of light tubes. “Draw Test” must be run in Single Point mode.
FAQ FAQ (8) Under “Multi-points” mode, why the cursor is not coincided with touch point after “Screen Calibration”? Enter “Control Panel”---“Tablet PC Setting”---“Display” and click on “Reset”. (9) How to adjust the sensitivity of “Double Click” under “Multi-Points” mode? Double click the “Pen and Gesture” icon in the taskbar and a dialog pops up: Adjust “Speed” and “Spatial Tolerance”. Then you can click the test figure on the right bottom to observe the effect. After finished, click “OK”.
Application of Checktool 6. Application of Checktool (1) Running Enter the destination folder of Fitouch and find the folder named as “checkTool”. Open the folder and double click “checktool.exe” to display the dialog: 2011-07-06 Run Checktool, there are “ DeviceInfo”, “Init”, “CheckAll”, “CheckOne”, “CheckAllResult” in the interface. If the device is not connected, the entire select buttons can not be selected and VersionInfo shows Unknow. If the device is connected, Please start testing.
TV Operating Voltage Power Consumption ~100-240V AC,50/60Hz 430(Max),＜1W(Standby) COMPONENT Video Format Supporting HDMI Input Frequency Digital TV Australia Channel Bandwidth 7MHz Video Decode 1080i,720p,576p,576i Audio MPEG;AC3 TV System PAL B/G;D/K;I NICAM NICAM Stereo 1329.12mm(H) X 747.63mm(V) 60.0 inches(1520mm) diagonal Analog TV Active Area Panel Spec 480i,480p,576i,576p,720p(50Hz/60Hz), 1080i(50Hz/60Hz),1080P(50Hz/60Hz) 480p,576p,720p(50Hz/60Hz),1080i(50Hz/60Hz).
Touch-screen Specification Highest speed: The highest speed up to 300 dots coordinate scond in the world can provide users with a prompt response and perfect reappearing of hand writing. it is the best choice for interactive whiteboard. Fault-tolerant design: The featured Fault-tolerant design can automatically detect and reset within 2 seconds once the equipment goes abnormally with high reliability. Various adaptation: With design of anti-glare, anti-dust, anti-static, anti-electromagnetic interference.
