Index 1. Notice before using 2. Package List 3. Product Introduction 4. Charging the Headset 5. Power On/ Off 6. Pairing the Headset (or any Bluetooth Device) 7. Wearing the Headset 8. Answering calls 9. Refusing calls 10. Ending calls 11. Voice Dialing 12. Redialing 13. Transferring calls 14. Maintaining calls 15. Ending Call 1 and answering Call 2 16. Triple Phone Conversation 17. Adjusting the Volume 18. Safety Instruction 19. Specifications 20. Excluding Problems 21. Storage of the Headset 22.
1. Notice before using Thank you for purchasing our Bluetooth Headset QLB10MH. First of all, please check to find everything in your package and carefully study the user guide to know the function details. QLB10MH is developed by the innovative Bluetooth wireless technology, enabled to connect the Bluetooth mobile phone designed with Audio Gateway PDA, desktop and notebook with the USB Bluetooth Dongle plugged-in, etc. Before using it, please confirm your mobile phone complies with Bluetooth V1.
3. Product Introduction Function (Answering/ Ending/ On/ Off) Button 3 LED (Indicator) Light Receiver (Speaker) Microphone Power Interface adapter (charging) Decrease Volume key (-) 1 Increase Volume key (+) 2 Note: ● For first time use, make sure to fully recharge the Headset battery.
4. Charging the Headset QLB10MH comes with a Lithium Polymer battery built-in. 1. Plug the travel charger into the power socket. 2. Plug the end of the travel charger into the power interface adapter of the Headset. 3. While charging, the indicator will turn red; when charging is completed, the red indicator will shut off or flashes red. Note: Charging time is around 90~120 minutes. ● For first time use, make sure to fully recharge the Headset up to 4 hours.
Note: ● While turning the Headset on, you will hear the “Du Du” sound from the receiver. The blue indicator light will flash 5 times, then 2 times, and after repeating this for 5 times, the indicator will flash the blue light every 3 seconds to come into a standby mode. ● While the Headset is turned on, it will automatically search for the paired device.
Bluetooth device, it will find QLB10MH. 5. Please choose and confirm QLB10MH. 6. Key in the Headset Password “0000” and press YES. If the pairing is successful, the indicator turns to flash the blue light only. For some mobile phones, after pairing you may have to select and confirm QLB10MH again to start the connection. (Please read your mobile phone manual carefully to take the right steps.) 7. The Headset is in the standby mode, you can start to receive and make call.
- One of the devices is re-switched on. 7. Wearing the Headset According to your preference, adjust the headset on your left or right ear. 160 160 8. Answering the calls 1. While there is a call coming, wait until you hear the ringing from your Headset receiver to press the function button to answer the call. 2. If the mobile phone is ringing first, wait until the Headset is ringing, then press the function button. 3. While answering the calls, the blue indicator light flashes 4 times each second.
4. If the mobile phone is ringing and your Headset is off, turn on your Headset first, then press the function button to answer the call. 5. If your mobile phone has the function of automatically receiving calls and you already set it up, while the call is coming, your Headset can receive the call automatically without pressing the function button. Note: ● The headset is with the function of passing the same ringing sound as the mobile phone if the mobile phone is with this function, such as Nokia. 9.
2. Under the standby or connecting mode, press the function button of the Headset and follow the mobile phone instructions to proceed with the voice dialing. Note: ● The activation of the voice dialing function will depend on the design of your mobile phone. ● The working range of the Bluetooth Headset is 5 meters indoors and 5~10 meters outdoors. 12. Redialing 1. If your mobile phone supports the redialing function, you can use this function with your Headset too. 2.
Note: ● To activate this function, your mobile phone must support the Handsfree mode. For more details, please check the manual of your mobile phone. 14. Maintaining calls 1. When you are answering the call with the Headset, press the decrease (-) volume key for 2~3 seconds until you hear one “Du” sound, then the call will be maintained. If there is an interrupting call coming, the Headset will answer it automatically. 2.
Press and hold the decrease (-) volume button for 2~3 seconds until you hear one “Du” sound followed by the music, Call 1 will be hold and the interrupting call (Call 2) will be answered automatically. Note: ● To activate this function, please make sure the assigned telecommunications agent provides this service. ● To activate this function, please refer to the instructions of your mobile phones manual to make sure your phone program supports this function. 16. Triple phone conversation 1.
Note: ● To activate this function, you must make sure the assigned telecommunications agent supports this service. ● To activate this function, please refer to the instructions of your mobile phones manual to make sure your phone program supports this function. ● When the triple phone conversation is on board, it can not return to the mode of having only Call 1 or Call 2.
2. Keep the Headset away from children, avoid children from swallowing it accidentally. 3. Do not use the cleaning liquid or spray to clean the Headset. 4. Do not clean the Headset while charging it. 5. Do not disassemble the Headset. If you encounter a problem, contact the retailer shop. ● Urgent handling -If you enconter a problem, turn the Headset off first. -If the inside components breakdown, please contact the repairing center to ask for immediate support and service. 19.
Data Encryption 128 bits encrypted Power Capacity Rechargeable Li-Polymer Power Supply 5V DC, 100~240V AC adapter Operation Temperature -10 ~ 55 ℃ Facility Saving Temperature -20 ~ 60 ℃ Operation Moisture 10% ~ 90% (non-concrete status) Weight 41.4 g (battery included) Size 166x144x48.5 mm Safety Regulation CE, BQB 20. Excluding Problems 1. The Headset flashes the red indicator light: The battery is low, please recharge your Headset. 2.
few minutes. 4. You hear no sound coming from the Headset: - Make sure the Headset has been paired with the other Bluetooth device. - Make sure the Headset is on. - Make sure the distance between the Headset and the paired Bluetooth device is within 10 meters. - Make sure your mobile phone has a good signal. - Some Bluetooth mobile phones support only one Headset, if you pair it with more than one Headset, it may cause the other Headsets being cut off. 21.
use it outdoors. - Connect the travel charger with the correct power supply. - Avoid pulling the cable to take the travel charger off the socket, it may damage the travel charger. [Battery] - New battery: for first time use, please fully recharge the battery for 4 hours. - Only authorized and qualified personnel can do battery changing. - Under the normal usage, the rechargeable battery can be used for the long time. - The battery must be recharged within temperatures of -10 ℃ to 45℃.
Q : Can QLB10MH work with any of the mobile phones? A : No, this Headset works only with Bluetooth mobile phones. Q : How far is the working distance between the Headset and the mobile phone? A : Since QLB10MH is certificated by BQB, compliable with Bluetooth V2.0 + EDR, Class II, the longest working distance is 10 meters. But, this working distance may be shortened by the interference existed in the surroundings and due to the insufficient Bluetooth function of the mobile phone.
A : No. The paired devices remain paired regardless of turning the power off, reopening the devices or changing the battery. Q : Why is the voice from the Headset not clear? A : It may be the following two reasons: (1) Your location has a bad signal, please move to a location with a better signal. (2) The working range between the Headset and the mobile phone has been exceeded.
Q : Why could the voice dialing function of the Headset not be switched on? A : (1) Please re-record the voice tag. (2) Some mobile phones do not support the voice dialing function. Please refer to the manual of your mobile phone. 23. Declaration of Conformity European CE 0678: QLB10MH has been manufactured in accordance with the European R& TTE directive. It complies with the European Low Voltage Directive 73/23/EEC and the European EMC Directive 89/336/EEC.
