Refrigerated Base Remote Condenser Spec Sheet

Job Item#
www.yatesgd.com www.yatesgraphicdesign.com
RefRigeRated Base
(Remote Condenser)
Standard Features
- Available in 32”, 36”, 48”, 60, 64”, 72”, 84”, 96”, and 108”
widths that can support any of the modular sectional
range tops
- Self-closing heavy-duty drawers slide on stainless steel
rollers
- Drawers hold standard sized (12” x 20” x 4”) pans -pans
not included
- Removable door assembly
- CFC-free refrigeration system has an expansion valve
for rapid temperature recovery -the remote condenser
unit is NOT included
- Foamed-in-place CFC-free polyurethane insulation
provides highest insulation factor available
- Rubber magnetic door gaskets provide a positive seal
and easy cleaning
- Stainless steel top, front, sides, back, drawers, and
interior cavity
- 6” adjustable stainless steel legs
- Coved interior corners (meets NSF standard #7)
- Condensate drain (1/2” I.D. tube) with standard electric
condensate evaporator pan.
- Adjustable digital thermostat
- Mullion coils are coated to resist corrosion and provide
maximum air ow for even cooling
- Operates on 120-volt single phase 50/60Hz AC power
- Warranty: two years on specied operational parts, ve
years on compressor, and one year on labor from date
of purchase
(Model 20072RSB with optional casters)
Printed in USA
Form PRR Rev 6 (August/2014)
STANDARD CONSTRUCTION SPECIFICATIONS
Exterior Finish: Top, front, sides, back, drawers, and interior cavity are 304 stainless steel #3 polish.
Drawers: Stainless steel -holds standard size (12” x 20” x 4”) pans -not included. Removable drawer assembly.
Base: 32-1/2” deep and 26” high, including adjustable legs or casters -32” units are 36” deep.
Refrigerant: R-404a -CFC-free. Uses an optional remote condenser.
20032RSB (32” wide); 20036RSB (36” wide);
20048RSB (48” wide); 20060RSB (60” wide);
20064RSB (64” wide); 20072RSB (72” wide);
20084RSB (84” wide); 20096RSB (96” wide);
20108RSB (108” wide)
