Ultimate RestaURant Range
24” seRies
Standard Features
- Commercial gas range, 24-3/8” wide with a 37” high cooking top
- 4”Stainless steel front rail, stainless steel front and sides
- Front located manual gas shut-off to entire range
- One year No Quibble, 24/7 parts and labor warranty
- Factory installed Regulator
- Four (4) removable, cast iron grate tops (rear holds up to 14”
stock pot
- Standing pilot for open top burners
- Battery spark ignition for oven bases
Optional 33K Non-clog Burners (Burner Option 1)
- (4) patented, one piece, lifetime clog free, cast iron burners
- 33,000 BTU NAT
Optional Wavy Grates (Burner Option 2)
- Castbowldesignforbetterefciency
- Allows full use of entire range top
- Available only with 27K BTU Non-clog burners
Optional Cast Iron Star/Saute' Burners (Burner Option 3)
- (4) 33,000 BTU NAT star burners
- Portarrangementallowsforevendistributionofame
Optional Split Burner Conguration (Burner Option 4)
- (2) Star/Saute’ burners in front and (2) standard 33K burners in rear
Printed in USA
CONSTRUCTION SPECIFICATIONS
Exterior Finish: Stainless steel front, sides and shelf standard.
RangeTop: 27” deep cooking surface. Center-to-center
measurements between burners not less than 12”, side-to-side or
front-to-back. A removable one piece drip tray is provided under
burners to catch grease drippings.
Flue Riser:22.5”ueriserstandardwithheavydutyshelf.Optional
10”and5”ueriseravailablewithoutshelf.
Oven Door: Spring assisted, counterweight door.
Oven Interior: Double sided, full porcelain enamel oven cavity for
superior cleanability and corrosion protection. Coved corners for easy
cleaningandenhancedairoweliminatinghot/coldspots.
Legs: 6” stainless steel adjustable legs standard (casters optional)
Pressure Regulator: Factory installed.
Available Base Combinations
E or C
Space Saver Oven Models (E)
45,000 BTU NAT oven with standing pilot and thermostat range
of 175
0
F to 550
0
F (79
0
C to 288
0
C). Porcelain enamel interior
measuring 14” high x 19-1/2” wide x 26.5” deep. One rack with two
position side rails.
Stainless Steel Cabinet (C)
Stainless steel cabinet base. Availabe with optional, no-charge
doors that open from the center.
Form 424 Rev 10 (August/2014)
(4241E Shown)
Congureyourowncustomspecsheet
and model number at
www.BuildMyRange.com.
Refer to AutoQuotes for list pricing.
