15.0 TFT Active Matrix LCD Panel User Manual Getting Start Table of content ................................................................................................................................. 1 View of Monitor.................................................................................................................................. 2 Unpacking .........................................................................................................................................
15.
15.0 TFT Active Matrix LCD Panel User Manual Unpacking Our 15” LCD monitor shall be content with these following items. Make sure you get all these set ready, otherwise contact to your dealer or store which you purchased it. At last, feel free to contact us. 15” TFT LCD Monitor External Univ15 pin D-sub (RGB Analog) input signal cable Power Cord ADAPTER TECH. External Universal AC Adaptor STD-1203 (100-240V, 50/60Hz) Audio connector : stereo Phone Jack CD User’s manual Quick Start Guide Warning 1.
15.0 TFT Active Matrix LCD Panel User Manual Hardware Installation Be carefully to your LCD monitor, it’s very exquisite but easy to broken. Turn off LCD’s and PC’s power before you set it up. Follow our installation step by step. Input 【1】DC port：This is for connecting the power cable 【2】PC In : This can be connected with the D-Sub 15 pin signal Cable. 【3】LINE in：This can be connected to the audio-out connector of any sound resource.
15.0 TFT Active Matrix LCD Panel User Manual Hardware Installation Step by Step 1. Turn your LCD opposite carefully which can see all the connection port. 2. Inset the signal cable such as RGB analog (standard) to its own port, and the other side connects to computer. 3. Inset the Audio connector to its own port, and the other side connects to computer line out. 4. Put AC Adaptor and Power Cord together. 5. Inset the DC cable to its own port (DC in), and the other side connect to socket. 6.
15.0 TFT Active Matrix LCD Panel User Manual Angle of Inclination 1. 2. 3. In normal condition With Lock in, LCD lay back 0˚ ~ 15˚ (positive and negative 2˚) With Lock off , LCD can lay back up to 90˚ for hanging 1. 2. 3. Hanging 1. 2. 3. 4. 5. 6. Unlock Lay back the stand Use the tape measure to determine the position of two holes and mark them down. (112mm of the total length from eight edges) Pick the right drill to bore holes in the wall. Hammer the plastic ribbed anchor onto the holes for screw.
15.0 TFT Active Matrix LCD Panel User Manual Monitor Adjusting Menu control button There 5 keys for user to set up the monitor, including, “OSD menu “, “Auto Tune”, ”Increase<+>”,”Decrease<->”, “Power”. The following descriptions are the introduction of these Keys. Key Introduction 1. 2. 3. 4. 5. “Power”: Turn the LCD power on and off. When the power is on, the light is showing green, standby will be orange. “Auto Tune”: Auto adjust, menu left adjustment.
15.0 TFT Active Matrix LCD Panel User Manual Cleaning Notice 1. 2. 3. 4. Be gentle to clean the screen. Never, ever, using any kind of corrosiveness chemical dissolvent to clean the screen, it may hurt your screen surface. We suggest that using a clean camel hair brush or a soft, clean, lint-free cloth to wipe the screen. Don’t give any pressure directly to the LCD Precaution 1. 2. 3. 4. 5. 6. 7. Do not expose the monitor to direct sunlight or heat. Do not spill liquid on the monitor.
15.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode Option select 1. Press the OSD button to access menu. 2. Using Auto Tune for left adjustment. 3. Press OSD again for right adjustment. Contrast： Adjust the difference between light and dark area. Brightness: Adjust the brightness of the display. Main menu contrast adjust Main menu brightness adjust Clock： Adjust the frequency of the pixel. Phase： Adjust the phase of pixel clock.
15.0 TFT Active Matrix LCD Panel User Manual EXIT : Saving and Leave. Main menu EXIT adjust Miscellaneous Horizontal Position： Adjust the horizontal position of the OSD. Return : Return to main menu. Return OSD H position adjust Horizontal Position： Adjust the horizontal position of the display. Vertical Position： Adjust the vertical position of the OSD. OSD V position adjust Auto color： Adjust the color automatically. OSD duration adjust Volume : Adjust of speaker.
15.0 TFT Active Matrix LCD Panel User Manual DISPLAY MODE Incoming Display Mode 1. 2. 3. 4. 5. Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 640X350 31.475 70.100 640X480 31.469 59.940 640X480 37.500 75.000 720X400 31.469 70.087 800X600 37.879 60.317 800X600 46.875 75.000 1024X768 48.363 60.004 1024X768 60.023 75.029 We offer you 8 available modes compatible with Windows. If any interference occurs on your screen while you modulating your PC or OSD.
