Schematic

7-Bit I2C Address: 0x5A
VCC: 2-5.2V
Clear jumper to remove
pull-ups from I2C bus
2.2k 2.2k
GND
VCC
VCC
JUMPER-PAD-3-NC_BY_PASTE
GND
DRV2605L
1.0uF
VCC
GND
1.0uF
GND
VCC
R1 R2
I2C
JP2
1
2
JP1
1
2
3
4
5
6
REG
SCL
SDA
IN/TRIG
EN VDD/NC
OUT+
GND
OUT-
VDD
U1
C3
C1
v20
Mary West
Released under the Creative Commons
Attribution Share-Alike 4.0 License
https://creativecommons.org/licenses/by-sa/4.0/
Design by:
