4-CHANNEL TRIPLEX NETWORK DVR DVR-T4IP USER MANUAL
Table Of Contents
- 1. SYSTEM OVERVIEWS
- 1.1 Packing list
- 1.2 Features & specifications
- 1.3 Name, function & connections
- 1.4 INSTALLATION
- 2. Basic operation procedures
- 3. Main Setup screen
- 3.1 Camera Setup menu
- 3.2 Record Setup menu
- 3.3 Event Setup Menu
- 3.4 Playback Setup
- 3.5 Display Setup screen
- 3.6 Network Setup screen
- 3.7 System Setup screen
- 3.8 Backup
- 3.9 System Information
- 3.10 Search Menu
- 3.11 PLAYBACK
- 3.12 Miscellaneous Menu
- 4. DVR-T4IP Client program
- 4.1 Overview of DVR-T4IP
- 4.2 Installation & execution of program
- 4.3 RAMS (Remote Access & Monitoring System)
- 4.3.1 Screen and button
- 4.3.2 Connecting to DVR
- 4.3.3 Channel On/Off
- 4.3.4 UniPlayer link
- 4.3.5 Full-screen display
- 4.3.6 Program setup
- 4.3.7 DVR recording
- 4.3.8 DVR playback search
- 4.3.9 DVR playback search
- 4.3.10 DVR backup
- 4.3.11 DVR Setting
- 4.3.12 Still image Capture
- 4.3.13 Watermark insertion
- 4.3.14 Printing still image
- 4.3.15 Motion picture recording
- 4.3.16 D-Zoom
- 4.3.17 PAN/TILT, ZOOM/FOCUS
- 4.3.18 HDD Information
- 4.3.19 Check the program version
- 4.3.20 S/W upgrade of DVR
- 4.3.21 Close program
- 4.4 UniPlayer
- 4.4.1 Screen and button
- 4.4.2 Search
- 4.4.3 Searching by directory
- 4.4.4 Still Image Capture
- 4.4.5 Input water mark
- 4.4.6 Printing still image
- 4.4.7 D-Zoom Function
- 4.4.8 Moving picture file playback, playing, pause, temporarily pause, move by interval of frame, fast forward Playing
- 4.4.9 Water mark drawing
- 4.4.10 Panorama
- 4.4.11 Check the program version.
- 4.4.12 Close Program
- 4.5 MultiViewer
- 4.6 Quick Installer
- 5. Appendix
118
5.3 Factory Default Value
5.3.1 Main Menu
Menu
Main
menu
Sub menu1 Sub menu2 Sub menu3
Default Value Remarks
Channel Channel No CH-1~CH-4
Camera Name CH-1~CH-4
Camera Hide Off
Model No NONE URX-500,
PELCO-D,
SENSORMATIC,
VICON,
SUNGJIN
MRX-1000
SRX-100B
PTZ ID Channel No
Reverse Control Pan NO
Tilt NO
Zoom NO
Focus NO
PTZ Setup
RS-485 Setting Baud Rate 9600
Default
Contrast 9 Level Max. 16 Levels
Brightness 9 Level “
Hue 9 Level “
Sharpness 9 Level “
Picture Setting
Default
Camera
Setup
Sequence Time 2 sec
Record Type MUX MUX/QUAD
MUX 360*240(NTSC)
360*288(PAL)
Resolution
QUAD 720*480(NTSC)
720*576(PAL)
Audio Sync NONE
Channel No CH1
Quality FINE 4 Levels
Frame Rate (FPS) 30
Record
Setup
Channel
Record Mode MANUAL
Channel No CH-1
Sensitivity 5 Level 8 Levels
Motion Detection
Setting
Detection Zone ALL
Sensor Type N.O. / N.C. N.O. Sensor Setting
Channel Link CH1~CH4 NONE
Sensor1~Sensor4 OFF
Motion1~Motion4 OFF
Alarm Output
Relay Time 0 sec
Post-Alarm Record 10 sec 10, 20, 20, 40, 50, 60
sec
FTP Server IP Blank
Event
Setup
FTP Setting
ID Anonymous
