5.5 HDD recording time table
(Based on recording mode, Resolution, picture Quality, FPS)
Recording time per HDD capacity (HR)
TV
System
Record
Mode
Resolution Quality
Frame
Rate
(fps/CH)
80GB 120GB 160GB 200GB 300GB
30 39.4 58.1 79.3 97.4 145.7
15 82.0 120.8 165.0 202.7 303.0
Super
Fine
7 166.9 245.9 336.0 412.8 617.0
30 60.4 89.0 121.6 149.4 223.3
15 133.0 196.0 267.8 329.1 491.8
Fine
7 278.1 409.9 559.9 688.0 1028.4
30 82.7 121.9 166.5 204.6 305.7
15 180.0 265.2 362.3 445.2 665.4
Enhanced
7 417.2 614.8 839.9 1032.1 1542.6
30 103.1 152.0 207.6 255.1 381.3
15 213.5 314.6 429.7 528.0 789.2
360*240
Normal
7 483.1 711.9 972.5 1195.0 1786.2
7 44.3 65.3 89.3 109.7 163.9
5 67.0 98.7 134.9 165.7 247.7
Super
Fine
3 100.9 148.6 203.1 249.5 372.9
7 65.6 96.6 132.0 162.2 242.4
5 99.8 147.0 200.9 246.8 368.9
Fine
3 150.5 221.7 302.9 372.2 556.3
7 80.5 118.7 162.1 199.2 297.7
5 119.2 175.7 240.0 294.9 440.7
Enhanced
3 176.5 260.1 355.4 436.6 652.6
7 90.9 133.9 183.0 224.8 336.0
5 133.0 196.0 267.8 329.1 491.8
MUX
720*480
Normal
3 204.0 300.6 410.6 504.6 754.2
30 45.6 67.1 91.7 112.7 168.4
15 81.2 119.7 163.5 200.9 300.3
Super
Fine
7 204.0 300.6 410.6 504.6 754.2
30 68.5 100.9 137.9 169.4 253.3
15 124.9 184.0 251.4 308.9 461.7
Fine
7 274.0 403.8 551.6 677.8 1013.1
30 85.8 126.4 172.7 212.2 317.2
15 156.9 231.2 315.9 388.1 580.1
Enhanced
7 346.4 510.4 697.3 856.8 1280.6
30 96.6 142.4 194.5 239.0 357.2
15 178.2 262.7 358.8 440.9 659.0
NTSC
QUAD 720*480
Normal
7 399.1 588.1 803.4 987.2 1475.5
