4-CHANNEL TRIPLEX NETWORK DVR DVR-T4IP USER MANUAL
Table Of Contents
- 1. SYSTEM OVERVIEWS
- 1.1 Packing list
- 1.2 Features & specifications
- 1.3 Name, function & connections
- 1.4 INSTALLATION
- 2. Basic operation procedures
- 3. Main Setup screen
- 3.1 Camera Setup menu
- 3.2 Record Setup menu
- 3.3 Event Setup Menu
- 3.4 Playback Setup
- 3.5 Display Setup screen
- 3.6 Network Setup screen
- 3.7 System Setup screen
- 3.8 Backup
- 3.9 System Information
- 3.10 Search Menu
- 3.11 PLAYBACK
- 3.12 Miscellaneous Menu
- 4. DVR-T4IP Client program
- 4.1 Overview of DVR-T4IP
- 4.2 Installation & execution of program
- 4.3 RAMS (Remote Access & Monitoring System)
- 4.3.1 Screen and button
- 4.3.2 Connecting to DVR
- 4.3.3 Channel On/Off
- 4.3.4 UniPlayer link
- 4.3.5 Full-screen display
- 4.3.6 Program setup
- 4.3.7 DVR recording
- 4.3.8 DVR playback search
- 4.3.9 DVR playback search
- 4.3.10 DVR backup
- 4.3.11 DVR Setting
- 4.3.12 Still image Capture
- 4.3.13 Watermark insertion
- 4.3.14 Printing still image
- 4.3.15 Motion picture recording
- 4.3.16 D-Zoom
- 4.3.17 PAN/TILT, ZOOM/FOCUS
- 4.3.18 HDD Information
- 4.3.19 Check the program version
- 4.3.20 S/W upgrade of DVR
- 4.3.21 Close program
- 4.4 UniPlayer
- 4.4.1 Screen and button
- 4.4.2 Search
- 4.4.3 Searching by directory
- 4.4.4 Still Image Capture
- 4.4.5 Input water mark
- 4.4.6 Printing still image
- 4.4.7 D-Zoom Function
- 4.4.8 Moving picture file playback, playing, pause, temporarily pause, move by interval of frame, fast forward Playing
- 4.4.9 Water mark drawing
- 4.4.10 Panorama
- 4.4.11 Check the program version.
- 4.4.12 Close Program
- 4.5 MultiViewer
- 4.6 Quick Installer
- 5. Appendix
125
Recording time per HDD capacity (HR)
TV
System
Record
Mode
Resolution Quality
Frame
Rate
(fps/CH)
80GB 120GB 160GB 200GB 300GB
25 42.5 62.6 85.5 105.1 157.1
12 71.2 104.9 143.2 176.0 263.1
Super
Fine
6 141.2 208.1 284.3 349.3 522.1
25 61.6 90.8 124.0 152.4 227.8
12 125.7 185.3 253.1 311.0 464.9
Fine
6 223.9 329.9 450.7 553.8 827.7
25 98.7 145.4 198.7 244.1 364.9
12 183.6 270.5 369.6 454.1 678.7
Enhanced
6 306.0 450.9 615.9 756.8 1131.2
25 120.8 178.0 243.1 298.8 446.5
12 241.5 356.0 486.3 597.5 893.1
360*280
Normal
6 367.1 541.1 739.1 908.2 1357.5
6 46.8 69.0 94.3 115.8 173.1
4 74.0 109.1 149.0 183.1 273.7
Super
Fine
3 92.7 136.6 186.6 229.3 342.8
6 67.0 98.7 134.9 165.7 247.7
4 108.0 159.1 217.4 267.1 399.3
Fine
3 129.3 190.5 260.3 319.8 478.0
6 81.2 119.7 163.5 200.9 300.3
4 125.7 185.3 253.1 311.0 464.9
Enhanced
3 153.0 225.4 308.0 378.4 565.6
6 90.9 133.9 183.0 224.8 336.0
4 137.0 201.9 275.8 338.9 506.5
MUX
720*576
Normal
3 170.0 250.5 342.2 420.5 628.5
25 51.0 75.1 102.7 126.1 188.5
12 72.0 106.1 144.9 178.1 266.2
Super
Fine
6 158.3 233.2 318.6 391.5 585.1
25 75.9 111.8 152.7 187.6 280.5
12 132.1 194.6 265.9 326.7 488.3
Fine
6 211.0 311.0 424.8 522.0 780.2
25 91.3 134.6 183.9 225.9 337.7
12 163.9 241.5 330.0 405.5 606.0
Enhanced
6 262.2 386.5 528.0 648.7 969.6
25 102.0 150.3 205.3 252.3 377.1
12 187.3 276.1 377.1 463.4 692.6
PAL
QUAD 720*576
Normal
6 306.0 450.9 615.9 756.8 1131.2
