4-CHANNEL TRIPLEX NETWORK DVR DVR-T4IP USER MANUAL
Table Of Contents
- 1. SYSTEM OVERVIEWS
- 1.1 Packing list
- 1.2 Features & specifications
- 1.3 Name, function & connections
- 1.4 INSTALLATION
- 2. Basic operation procedures
- 3. Main Setup screen
- 3.1 Camera Setup menu
- 3.2 Record Setup menu
- 3.3 Event Setup Menu
- 3.4 Playback Setup
- 3.5 Display Setup screen
- 3.6 Network Setup screen
- 3.7 System Setup screen
- 3.8 Backup
- 3.9 System Information
- 3.10 Search Menu
- 3.11 PLAYBACK
- 3.12 Miscellaneous Menu
- 4. DVR-T4IP Client program
- 4.1 Overview of DVR-T4IP
- 4.2 Installation & execution of program
- 4.3 RAMS (Remote Access & Monitoring System)
- 4.3.1 Screen and button
- 4.3.2 Connecting to DVR
- 4.3.3 Channel On/Off
- 4.3.4 UniPlayer link
- 4.3.5 Full-screen display
- 4.3.6 Program setup
- 4.3.7 DVR recording
- 4.3.8 DVR playback search
- 4.3.9 DVR playback search
- 4.3.10 DVR backup
- 4.3.11 DVR Setting
- 4.3.12 Still image Capture
- 4.3.13 Watermark insertion
- 4.3.14 Printing still image
- 4.3.15 Motion picture recording
- 4.3.16 D-Zoom
- 4.3.17 PAN/TILT, ZOOM/FOCUS
- 4.3.18 HDD Information
- 4.3.19 Check the program version
- 4.3.20 S/W upgrade of DVR
- 4.3.21 Close program
- 4.4 UniPlayer
- 4.4.1 Screen and button
- 4.4.2 Search
- 4.4.3 Searching by directory
- 4.4.4 Still Image Capture
- 4.4.5 Input water mark
- 4.4.6 Printing still image
- 4.4.7 D-Zoom Function
- 4.4.8 Moving picture file playback, playing, pause, temporarily pause, move by interval of frame, fast forward Playing
- 4.4.9 Water mark drawing
- 4.4.10 Panorama
- 4.4.11 Check the program version.
- 4.4.12 Close Program
- 4.5 MultiViewer
- 4.6 Quick Installer
- 5. Appendix
15
1.2.2 Specifications
Item Description
Image System NTSC, PAL selectable
Video Input 4CH Composite, 4CH Loop through, BNC
Video Output 1CH Composite, BNC, 1CH S-Video
Video Compression MPEG-2
Quad
NTSC: 720x480 (30fps)
PAL : 720x576 (25fps)
Recording
Resolution
MUX NTSC: 720x480 (30fps), 360x240 (120fps)
PAL : 720x576 (25fps), 360x288 (100fps)
Recording Quality 4 Levels (Normal, Enhanced, Fine, Super Fine)
NTSC: 1/30,1/15,1/10,1/7,1/5,1/3,1/2,1 (8 Steps)
Recording Speed
PAL: 1/25,1/12,1/10,1/6,1/5,1/3,1/2,1 (8 Steps)
Playback Type Quad / Mux
Playback Search Date/Time, Event (Alarm, Motion detection)
Playback Speed x1/4,x1/2,x1, x2, x4, x8, x16, x32, x64, x128, Field by Field
(Forward/Backward)
Sensor Input 4 (NO/NC Selectable)
Alarm Output 1 (NO/NC)
Aux Control In/Out 2/3 (Selectable Function Menu)
Alarm Reset In, Record Start In, Record ON/OFF, Alarm Out,
Error Out, Record Start Out, Disk Full Out, Record Status Out
Audio 1CH, mono, mute or NOT SUPPORT
Network 10Base-T (STATIC,DHCP, PPPoE, E-mail, & FTP)
Motion Detection 11x8, 8 Level Sensitivity
Hard Disk Removable+ Internal
Backup Method Removable HDD , CD-RW,
USB Memory, Network
Watermarking Backup
PTZ Control RS-485
System Log Video Loss, Power On, Power Off, Menu Called, HDD Full,
FTP Fail, E-mail Fail, etc
Password Function Power ON/OFF, MENU, Record OFF, Key Lock
Digital Zoom x 2
Timer Built-in Real time clock
Power Source Free Voltage (100 - 240VAC, 50Hz/60Hz, 50W)
Dimension 433(W) x 385(D) x 88(H)
Operating Temperature
5℃ ~ 40℃
Weight 5.5Kg (w/o HDD)
Design and specifications are subjected to change without notice.
