“BASE” permanently displayed if the receiver is used
as a base, otherwise position computation status if the
receiver is used as a rover. In the latter case, the
position computation status may take one of the
following values:
– Column #2:
Current value of PDOP.
Age of corrections in all differential modes (Blank if no
corrections received, or if a base).
– Column #3: Current values of HRMS and VRMS
– Column #4: “REC” if the raw data logging option is
unlocked and active.
• [2]: Name of the currently open job.
• [3]: This symbol shows your current position. The arrow
points in your last walking direction.
• [4]: Current zoom setting. The current value of scale is
provided, based on the currently selected unit.
• [5]: Current 3D position of the receiver (no coordinates
displayed if the receiver has not determined its position
yet).
• [6]: Log button. Use this button to log the position of the
point where the external antenna is currently located. The
button is grayed until GPS positions are computed and a
job is open. You can use either the on-screen Log button
or the left-hand “–” key on the keyboard to access the Log
function.
• [7]: Button used to show or hide the virtual Microsoft
keyboard.
• [8] Menu button. Gives access to the ProMark Field
function menu. You can use either the on-screen Menu
button or the right-hand “–” key on the keyboard to show
or hide the function menu.
Status Operating Mode
Autonomous GPS only
DGPS
Conventional Differential GPS using corrections from a
beacon or a base.
SDGPS SBAS Differential
FLOAT RTK, subfoot accuracy
FIXED RTK, centimeter accuracy
