The UL633 is the rst construction laser to enable
the total control of all three axes (X/Y/Z). This is
accomplished via unique simultaneous Radio and
Infrared communication and also completely new
“fan beam” technology for the Z axis.
Beneting from Spectra Precision’s know-how, the
UL633 is appropriate for all applications delivering an
easy, fast and accurate job.
Applications
General Construction

Leveling concrete forms and footers

Vertical alignment such as
anchor bolt and form alignment
Machine Guidance Compatible

Dual slope grading and steep
slope excavating

Slope work for sports elds,
tennis courts, driveways,
parking garages, ramps
Pipe and Drainage Installations

Automatic Alignment for pipe laying

Measuring unknown slopes
in existing pipes
Interior

Layout of walls

Installation of drop ceilings
The Most Versatile Construction Laser, Ever
UL633
Total Control of X/Y Axes

Unlimited Automatic Dual Axis Features
- High Precision Axis Alignments
- Simplied Grade Match: measures and
displays the existing grade over unknown ground
- Complete PlaneLok: automatically locks on
the laser beam to an existing elevation

All functions exible from 10 to 170 degrees

Horizontal Angle Measurement capability
Total Control of Z Axis

Automatic Detection of plumb beam
- Spot Align: aligns the plumb beam to a
desired position
- Spot Match: displays the measured Z-axis
grade value
- SpotLok: locks automatically the plumb
beam to the SF601 center point

Manual Detection of plumb beam
- Spot Search

Complete Cross Axis Compensation
Versatile Communication Links

Radio (2 radio channels)

IR
Built for Today’s Jobs

Fully automatic up to +/-25% grade on X/Y/Z axes

Withstands a 1 m (3 ft) drop onto concrete

Long operating range - 800 m (2.600 ft) diameter

Intuitive keypad

Mask mode

Various power options

Automatic temperature compensation

Electronic leveling vibration lter

Versatility to t any construction application

Quickly adapts to site requirements

Simplies 90° layout applications

Reduces time to do slope work and pipe installation
Key Features
User Benets
