Polycom® KIRK® Base Station 1.8/1.
1 Introduction The base station is only intended for use with a wireless server. The base station is not intended to be connected directly to the PSTN network. The base station is designed with two internal antennas and supports antenna diversity. The base station is also able to carry out a handover between the RF channels under the same base station, and handles four DECT speech channels simultaneously. The base station is able to frame synchronize with other base stations under the same wireless server.
(maximum supply 1.5 W). The DECT radius of coverage is up to 600 meters/1960 feet with a handset in free sight. 2 Installation First you have to determine where to install the base station to have the right coverage. The average coverage within buildings is 75 meters/246 feet. The coverage depends on the construction of the building, architecture and choice of buildings materials. You may have to use the Deployment Kit to optimize your installation. The base station is to be mounted vertically on the wall.
Holes for wall mounted screws Power supply
1 Use a twisted pair cable, e.g. cat.4 between the base station and wireless server with an RJ11 connector at the base station end of the cable. Connect the cable to the plug using the two inner connectors of the plug. 2 Mount the base station onto the wall using the screws accompanyiing the base station. 3 Connect the base station to the wireless server. After the wireless server is powered up again, a cable lenght measurement is needed. Note: Cable dimensions min. as AWG 26.
Important Safety Instructions and Product Information Before using your telephone equipment, you should always follow basic safety instruction to reduce the risk of fire, electrical shock and injury to persons, and damage to property. 1 Read and understand all instructions 2 Follow all warnings and instructions including those marked on the product 3 Unplug this product before cleaning. Do not use liquid cleaners or aerosol cleaners.
5 Slots or openings in the cabinet back and bottom of the equipment are provided for ventilation to protect it from over-heating. These openings must not be blocked or covered. 6 The equipment is to be connected only to the PoE networks without connection to outside plant. 7 The equipment is to be connected to a UL listed PoE server 8 Do not overload wall outlets and extension cords as this can result in fire or electrical shock.
out parts that could result in fire, electrical shock, or injury. Never spill liquid of any kind into this product. 10 To reduce the risk of electrical shock or burns, do not disassemble this product. Opening or removing covers may expose you to dangerous voltages, dangerous electrical current, or other risks. Incorrect reassemble can cause electrical shock when the appliance is subsequently used. If the product need repair, consult your dealer.
CQ If the product does not operate normally when following the operating instructions in the manual. Adjust only those controls that are covered by the operation instructions. Improper adjustment of other controls may result in damage and will often require extensive work by qualified service personnel to restore the product to normal operation.
3 Do not use the telephone to report a gas leak in the vicinity of the leak 4 Do not place the unit near microwave ovens, radio equipment, or non-ground connected televisions. These appliances may cause electrical interference to the base or handset 5 Installation must be performed in accordance with all relevant national wiring rules. 6 The system will not operate in the event of a blackout.
Exposure to sunlight, heat and moisture Do not expose the unit to direct sunlight for long periods. Keep away from excessive heat and moisture. Spare parts and accessories Use only approved spare parts and accessories. The operation of non-approved parts cannot be guaranteed and may even cause damage.
users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be coordinated by a representative designated by the supplier.
power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. CAUTION: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.
will be informed of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the proper functioning of your telephone system, If they do and it is possible, you will be notified in advance to give you an opportunity to mainta- in uninterrupted telephone service.
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/ TV technician for help. FCC Note: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may may cause undesired operation.
The term “IC:” before the certification /registration number only signifies that the Industry Canada technical specifications were met. CAUTION: Privacy of communication may not be ensured when using this phone. Power Outage: In the event of a power outage, your cordless telephone will not operate. The cordless telephone requires electricity for operation. You should have a telephone which does not require electricity available for use during power outages.
ance could void the user’s authority to operate the equipment. LIMITED WARRANTY This limited, non-transferable warranty is provided to the original purchaser. The product is warranted to be free from defects in materials and workmanship under normal installation, use and service for a period of one (1) year from the date of purchase as shown on the purchaser’s receipt.
returned must be accompanied by a copy of the purchase receipt. In the absence of a purchase receipt, the warranty period shall be one (1) year from the date of manufacture. Repair or replacement of the product is your sole and exclusive remedy. If the product is repaired, reconditioned component parts or materials may be used. If the product is replaced, we may replace it with a new or reconditioned product of the same or similar design.
while in transit to service facility. We do not warranty that the product will be compatible with any telephone equipment, systems or party lines. This warranty shall be void of the product is damaged as a result of defacement, misuse, abuse, neglect, accident, destruction or alteration of the serial number, improper electrical voltages or currents, repair, alteration or maintenance by any person or party other than our authorized service facility, or any violation of instructions furnished by us.
was not designed. Due to variations in telephone systems and communications laws, this product may be illegal for use in some countries. We assume no responsibilities for damages or penalties incurred resulting from the use of this product in a manner or location other than that for which it was intended. THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED.
NIENCE, INJURY TO ANY PERSON, OR DAMAGE TO PROPERTY CAUSED BY THE PRODUCT, LOSS OF REVENUE OR PROFIT OR DAMAGES FOR ANY FAILURE TO PERFORM. IN NO EVENT SHALL WE BE LIABLE FOR ANY SPECIAL, INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES EVEN IF WE ARE ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. This warranty is the sole and exclusive warranty provided for the product.
Appropriate RFsafety/installation information The base station is intended to be installed by authorized personal. The base station shall be installed in accordance with FCC rules. The base station shall be placed at a location in such way, that there is at least 20 centimeters/8 inches between the base transmitter and the users body or any other nearby persons.
International Regulatory Information This KIRK product has been marked with the CE mark. This mark indicates compliance with EEC Directives 89/ 336/EEC, 73/23/EEC 1999/5/EC. A full copy of the Declaration of conformity can be obtained from Polycom Ltd, 270 Bath Road, Slough, Berkshire, SL1 4DX, UK.
1405 7200-HD, ed.9 Polycom (Denmark) Langmarksvej 34 DK-8700 Horsens Tlf. +45 7560 2850 Fax +45 7560 2851 www.polycom.
