User's Guide for Dryers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) www.alliancelaundry.com Part No.
WARNING IMPORTANT: Purchaser must consult the local gas supplier for suggested instructions to be followed if the dryer user smells gas. The gas utility instructions plus the SAFETY and WARNING note directly above must be posted in a prominent location near the dryer for customer use. WARNING Risk of fire. Highly flammable material. WARNING W881 Read all instructions before using unit.
The following information applies to the state of Massachusetts, USA. • This appliance can only be installed by a Massachusetts licensed plumber or gas fitter. • This appliance must be installed with a 36 inch [910 mm] long flexible gas connector. • A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance. • This appliance must not be installed in a bedroom or bathroom. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 4 Part No.
Product Registration Product Registration New owners of Alliance Laundry Systems equipment are encouraged to register their appliance to insure proper limited warranty coverage. Register online at http://www.speedqueen.com/home/en-us/support/product-registration.aspx or contact your dealer to register your appliance. All information will be kept confidential and will not be distributed to other parties. © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 5 Part No.
Table of Contents Product Registration............................................................................... 5 Safety Information...................................................................................7 Explanation of Safety Messages.....................................................................7 Important Safety Instructions......................................................................... 7 Before Drying.....................................................................
Safety Information Safety Information • Install this dryer according to the INSTALLATION INSTRUCTIONS. Refer to the EARTH/GROUND INSTRUCTIONS in the INSTALLATION manual for the proper earth/ground connection of the dryer. All connections for electrical power, earth/ ground and gas supply must comply with local codes and be made by licensed personnel when required. Do not do it yourself. • Do not install or store the dryer where it will be exposed to water and/or weather.
Safety Information • Remove laundry immediately after the dryer stops. • DO NOT operate the dryer if it is smoking, grinding or has missing or broken parts or removed guards and/or panels. DO NOT tamper with the controls or bypass any safety devices. • DO NOT operate individual units if they have been separated from a stack unit. • Dryer will not operate with the loading door open. DO NOT bypass the door safety switch by permitting the dryer to operate with the door open.
Before Drying Before Drying 1. Sort by color. 2. Separate lint shedding fabrics and lint receiving fabrics. Towels, flannels, chenille, cottons, rugs, etc., shed lint. Corduroys, knits (including socks), permanent press, and synthetics attract lint. 3. Separate no heat, low heat and high heat items. Energy Saving Tips • • • • • • • • • • Make sure the lint filter is always clean. Do not overload the dryer. Do not overdry items. Remove items to be ironed while still damp.
Before Drying Cylinder with wet permanent press items D666I_SVG © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 10 Part No.
Operating Your Dryer Operating Your Dryer WARNING To reduce the risk of fire, electric shock, serious injury or death to persons, read the Safety Information section before operating the dryer. W520 When a wet load is put into the dryer it takes a certain amount of time to reach the desired dryness level. The time will vary with load size, type of fabric, amount of moisture in the load, air flow and the laundry room environment. The estimated time will be shown in the digital display.
Operating Your Dryer 2. Press the keypads for the desired cycle, selection and option settings. 3. Press the Favorite keypad to save the settings. The next Favorite cycle, F2, will be displayed. It can be programmed now. 4. Press the Start/Pause or Delay Start keypad to save the settings and start the cycle. 5. Press the Power/Cancel keypad to discard the current settings and exit Favorite mode. The Wet, Damp and Dry lights will be lit based on readings from the moisture sensing system.
Operating Your Dryer Status WARNING The Status lights are lit during the cycle to show what part of the cycle is running. Door Open To reduce the risk of fire and risk of lint collecting in exhaust duct, do not operate dryer without lint filter in place. The Door Open status light is lit any time that the dryer door is open. Heating The Heating status light is lit to indicate that a heat portion of the cycle is currently operating.
Operating Your Dryer NOTE: To stop dryer at any time, open the door or press the Start/Pause button. To restart dryer, close door and press the Start/Pause button again. Optional Drying Rack A drying rack, Part No. D512082, is available at extra cost through your Factory Authorized Service Center. The drying rack can be used in manual cycles only for no-tumble drying of articles such as tennis shoes, sweaters, stuffed toys or other delicate items.
Maintenance Maintenance Lubrication WARNING All moving parts are sealed in a permanent supply of lubricant or are equipped with oilless bearings. Additional lubrication will not be necessary. Any disassembly requiring the use of tools must be performed by a suitably qualified service person. Care of Your Dryer W299 WARNING To reduce the risk of an electric shock, serious injury or death, disconnect the electrical service to the dryer before cleaning the interior.
Maintenance 1 DRY2782N_SVG 1. Lint Filter Figure 2 © Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 16 Part No.
Troubleshooting Troubleshooting Try these troubleshooting tips before making a service call. They may save you time and money. Dryer Symptom Possible Cause/Solution Dryer won’t start • Make sure the power cord is plugged all the way into the electrical outlet. • Make sure loading door is closed. • Press Start/Pause button to start dryer. • Make sure the laundry room fuse(s) isn’t blown or loose, or circuit breakers aren’t open. • The dryer itself does not have an electrical fuse.
Troubleshooting Dryer Symptom Possible Cause/Solution Dryer is noisy • Check dryer for foreign objects (nails, coins, bobby pins, metal, plastic toys, etc.). Remove items from dryer. • Make sure dryer is level. Uneven leveling can cause vibration. • Normal operating sounds include the heat source going on and off and the humming of air moving through the dryer and exhaust system. Clothes are too wrinkled • Check heat setting. Overdrying can cause wrinkling. • Check load size.
Troubleshooting Contact Information WARNING If service is required, contact the nearest Factory Authorized Service Center. To find the nearest service center, visit us online at www.speedqueen.com. To reduce the risk of serious injury or death, DO NOT repair or replace any part of the unit or attempt any servicing unless specifically recommended in the user-maintenance instructions or in published userrepair instructions that you understand and have the skills to carry out.
