User's Manual

Fig. 2
srl Gaming RECLINER
A. Backrest
B. Seat base with footrest
C. Backrest wings
D. Lumbar pillow
position
Parts and Supplies
Adjusting the reclining
Assembly Instructions
Set up your Reclining Gaming Chair in a space that will accommodate its
reclining position and 360° swiveling.
Important! The backrest alignment rails and the side guide rails have
sharp metal edges. Use caution when unpacking the parts, and when
attaching the backrest and sides to the seat.
Adjusting the Seat and
Footrest Position
While sitting in the upright position, pull the side lever to release the
footrest, which will pop up. Then recline by slowly sitting back in the
chair while gently pushing on the armrests.
To return the chair to the upright position, lean forward and take
your weight off the backrest. Press down with your legs to return the
footrest to the closed position.
Precautions
• Follow all safety precautions
during assembly of the
product.
• Make sure this product is
intact and that there are no
missing parts.
• Clean the chair with only a
soft, dry cloth.
• Make sure everything is
secure before use.
• Use the chair on a flat surface
only.
• Do not stand on the chair.
• Do not exceed the maximum
weight capacity of 275 lb.
(125 kg).
• Do not put your weight only on
the backrest while the chair is
in a reclined position.
• Do not let anyone press down
on the backrest while the
chair is in a reclined position.
• Recline the chair slowly.
• Do not sit on the arms or
backrest of the chair.
• All images are for illustrative
purposes only.
1. Place the seat base on a flat surface,
and lift the back flap of the backrest
to expose the attachment rails.
2. Align the rails with the brackets on
the seat base. Press the rails down
into the brackets until the locking
tabs snap closed [ Fig. 1 ].
3. Attach the wings by sliding them
down onto the backrest rails until
they’re snug [ Fig. 2 ].
4. Attach the touch-connect strip at the
bottom back of the backrest to the
strip at the bottom of the seat base.
Disassembly Instructions
1. Detach the touch-connect strips from the front and back of the
chair, and lift the back flap.
2. Pull the two locking tabs toward the center of the chair to unlock
the backrest. While pulling the tabs to the center of the chair, lift
the backrest up and out of the brackets.
3. Remove the backrest sides by lifting them up and off the guide
rails.
Upright Rocking
Swivel Reclined
A B C
Fig. 1
D
