APPROVAL SHEET Power supply MODEL NO: ENGINEER SP-R-400WTB-PFC NO: SUATX0400Z1ECAEU111 Audited by Article No. : SP-AP-SU-A126 Issue Date :2010-10-24 Version : A/0 Checked by Drafted by Spire Corp. Tel.: +86-755-26801567 Fax: +86-755-26801561 Http://www.spire-corp.com Http://www.spirepower.com Http://www.spirecoolers.
Spire Corp. Approval Sheet Revisement Record Article No: SP-AP-SU-A126 Version Revised Chapter Description A/0 N/A First Version Version:A/0 Revised Date Drafted Audited by by Http://www.spirepower.com & Http://www.spirecoolers.com Http://www.spire-corp.com ECN No.
Spire Corp. Contents 1 Introduction………………………………………………………………5 1.1 Scope………………………………………………………………………5 1.2 General Description………………………………………………….……5 2 Electrical………………………………………………………………………5 2.1 AC Input…………………………………………………..………………5 2.1.1 Input Over current Protection……………………………………5 2.1.2 Inrush Current Limiting…………………………….………………6 2.1.3 Withstand Voltage……………………………......……………...6 2.1.4 Catastrophic Failure Protection……………………….…………..6 2.2 DC Output……………………………………………………….…………6 2.2.1 DC Voltage Regulation……………….
Spire Corp. 2.4 Output Protection…………………………………………………………12 2.4.1 Over voltage Protection…………………………………………12 2.4.2 Over Current Protection…………………………………………12 2.4.3 Short-circuit Protection……………………………………………12 3 Mechanical……………………………………………………..……………12 3.1 AC Connector. ………………………………..…………………………12 3.2 DC Connector Pin Description…………………….……..……………13 4 Environmental…………………………..……………………………………14 4.1 Environmental (Operating)…………………..…………………………14 4.2 Environmental (Non-Operating)…………..
Spire Corp. 1 Introduction 1.1 Scope This specification defines the performance and characteristic for the model of SP-R-400WTB-PFC power supply. 1.2 General Description SP-R-400WTB-PFC is a switching power supply, 400W self-contained, AC to DC power source supply suitable for mounting in PC. 1) SPCC 0.8MM ENCLOSURE 2) one 120mm transparency with blue LED fan 3) Black Paint Case 4) Dimensions:140mm(L)X150mm(W)X85mm(H) 2 Electrical 2.
Spire Corp. 2.1.2 Inrush Current Limiting Maximum inrush current from power-on (with power on at any point on the AC sine) and including, but not limited to, three line cycles, shall be limited to a level below the surge rating of the input line cord, AC switch if present, bridge rectifier, fuse, and EMI filter components. Repetitive ON/OFF cycling of the AC input voltage should not damage the power supply or cause the input fuse to blow. 2.1.
Spire Corp. 2.2.2 Output DC Current Ranges All outputs are within the specified limits of regulation when each output is subjected to the conditions listed below. Table 3. DC Input Line Requirements Minimum Maximum Combined Output DC Nominal Voltage Current Current +12 V1 DC 0.8 A 18A 360W +12 V2 DC 0.8 A 18A 120W +5 V DC 0.3 A 20A 400W +3.3 V DC 0.3 A 16A - 12 V DC 0.0 A 0.3A 3.6W +5 V SB 0.0 A 2.5A 12.5W NOTE: 1)The combined power output of +5V and +3.3V shall not exceed 120W.
Spire Corp. 2.2.6 Output Ripple/Noise The output ripple/noise requirements listed in Table 5 should be met throughout the load ranges specified and under all input voltage conditions as specified. Ripple and noise are defined as periodic or random signals over a frequency band of 10 Hz to 20MHz. Measurements shall be made with an oscilloscope with 20 MHZ bandwidth. Outputs should be bypassed at the connector with a 0.1μF ceramic disk capacitor and a 10μF electrolytic capacitor to simulate system loading.
Spire Corp. 2.2.7 Output Transient Response The table below summarizes the output transient steps for each output. The Transient slew rate is =0.5A/μs. Table 6. DC Output Transient Response Specifications DC Output Maximum Step Size Output Voltage Tolerance +12V1DC +12V2DC +5VDC +3.3VDC -12VDC +5VSB 40% of rated output 60% of rated output 30% of rated output 30% of rated output 0.1A 0.5A ±5% ±5% ±5% ±5% ±10% ±5% 2.2.
Spire Corp. 2.2.11 Voltage Hold-up Time All output will stay within regulation for at least 16ms after an AC line voltage failure is detected at nominal line (230VAC) under full load condition. 2.3 Timing / Housekeeping / Control Figure 2. Power Supply Timing ~ T1 VAC_ON T5 VAC_OFF PS_OFF# ~ PS_ON# T2 +12VDC +5VDC ~ 95% O/P’s 10% +3.3VDC T3 ~ PWR_OK T4 T6 PWR_OK Sense Level=95% of nominal T1 0.
Spire Corp. 2.3.2 PS_ON# The power supply provides an internal pull-up to TTL high. The power supply also provides denounce circuitry on PS_ON# to prevent it from oscillating on/off at startup when activated by a mechanical switch. The DC output enable circuitry is SELV-complaint. Table 8. PS_ON# Signal Characteristics VIL, Input Low Voltage VIL, Input Low Current (Vin = 0.4 V) VIH, Input High Voltage (lin = -200 μA) VIH, open circuit, lin = 0 Min. Max. 0.0V 0.8V -1.6mA 2.0V 5.25V 2.3.
Spire Corp. 2.4 Output Protection Each DC output is protected from over voltage, over current and short circuit. The following sections include the details for these protection mechanisms. 2.4.1 Over voltage Protection The overvoltage sense circuitry and reference reside in packages that are separate and distinct from the regulator control circuitry and reference. No single point fault is able to cause a sustained overvoltage condition on any or all outputs.
Spire Corp. 3.2 DC Connector Pin Description PIN1 PIN13 Pin Color 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 1 2 3 4 Version:A/0 5 6 7 8 Signal Pin Color Orange Orange +3.3VDC 13 Brown Orange +3.3VDC 14 Blue Black COM 15 Black Red +5VDC 16 Green Black COM 17 Black Red +5VDC 18 Black Black COM 19 Black Gray PWR_OK 20 Purple +5VSB 21 Red Yellow +12VDC 22 Red Yellow +12VDC 23 Red Orange +3.3VDC 24 Black Signal +3.3VDC +3.
Spire Corp. 4 Environmental 4.1 Environmental (Operating) Temperature: 0℃ to 50℃ Humidity: 5% to 90% Relative Humidity (non condensing) Altitude: 0 meters to +3,048 meters Shock: T.B.S. Vibration: T.B.S. 4.2 Environmental (Non-Operating) Temperature: -40℃ to 70℃ Humidity: 5% to 85% Relative Humidity (non condensing) Altitude: 0 meters to +15,244 meters Shock: T.B.S. Vibration: T.B.S.
Spire Corp. 6 Reliability 6.1 Component Derating The following component derating guedelines are recommended: ‧Semiconductor junction temperatrues shall not exceed 110℃ with an ambient of 50℃. ‧Inductor case temperature shall not exceed safety agency requirements. ‧Capacitor case temperature shall not exceed 95% of rated temperature. ‧Component voltage and current derating shall be >10% at 50℃.
Version:A/0 1 2 2 Drawn 3 3 Checked Approved 4 4 DATE SATA Http://www.spirepower.com & Http://www.spirecoolers.com Http://www.spire-corp.com (+3.3V)ORANGE (GND)BLACK (+5V)RED (GND)BLACK (+12V)YELLOW (+3.3V)ORANGE (GND)BLACK (+5V)RED (GND)BLACK (+12V)YELLOW 5 Angles Version ±0.5 ° Page 6 1/1 A/0 N/A 250 Finish 250 ±0.40 over ±0.50 100 -±0.30 Scale Material N/A ±0.20 30 100 mm 30 Unit 10 ±0.
Spire Corp. 9 Photograph: Version:A/0 Http://www.spirepower.com & Http://www.spirecoolers.com Http://www.spire-corp.
Spire Corp. Version:A/0 Http://www.spirepower.com & Http://www.spirecoolers.com Http://www.spire-corp.
