Replacement Part List

Data Bulletin

1170DB0502

10/2005

Lexington, KY, USA

Homeline

Load Center Repair / Replacement Parts

Single-Phase Fixed Main Lugs

Electrical equipment should be installed, operated, serviced, and maintained only by

qualified personnel. No responsibility is assumed by Schneider Electric for any

consequences arising out of the use of this material.

Schneider Electric USA

1601 Mercer Road

Lexington, KY 40511 USA

1-888-SquareD (1-888-778-2733)

www.us.SquareD.com

NOTE: For specific part numbers, go to www.schneider-electric.us, click on Product FAQ’s, enter the device catalog

number, click SEARCH, then look for the information required. Photos are typical, and may vary slightly from your

actual device.

Part:

Indoor Cover Interior Assembly

Indoor Flush Cover Mounting Screw Indoor Surface Cover and RB Interior Trim /

Dead Front Mounting Screw

RB Cover / Door Mounting Screw

Neutral Bonding Screws (Green)

Interior Trim / Dead Front

RB Cover / Door
