Module Current Consumption
SPSGRF-868 module
Symbol
Parameter
T
est Conditions
Typ.
Unit
Idd Supply current
Operating mode
Tx , +11.6 dBm , 2-FSK , 868 MHz
22 mA
Operating mode
Tx , - 7 dBm , 2-FSK , 868 MHz
9 mA
Operating mode
Rx , 8685 MHz
10 mA
Command mode 0.6 mA
Shutdown High Level -Vdd
(with other I/O in High impedance)
0.1
µA
SPSGRF-915 module
Symbol
Parameter
T
est Conditions
Typ.
Unit
Idd Supply current
Operating mode
Tx , +11.6 dBm , 2-FSK , 915 MHz
22 mA
Operating mode
Tx , - 7 dBm , 2-FSK , 915 MHz
9 mA
Operating mode
Rx , 915 MHz
10 mA
Command mode 0.6 mA
Shutdown High Level -Vdd
(with other I/O in High impedance)
0.1
µA
Module RF compliance limits
The RF compliance limits are those tested for FCC and CE certification using the dedicated
DONGLE (PC92A.V01). These limits are enforced by the DONGLE firmware. Care must be taken
with custom application firmware to ensure these limits are not exceeded, voiding the FCC and CE
certification.
RF compliance limits table
Modulation
Standards
Parameter
Max.
Unit
2-FSK
GFSK
MSK
FCC Part 15.207 (1)
FCC Part 15.247 (1)
EN 300 220-2 V2.4.1 (2)
EN 301 489-01 V1.9.2 (2)
EN 301 489-03 V1.4.1 (2)
Data rate 500 kbps
Conducted
Output power
+11.6 dBm
OOK
ASK
FCC Part 15.207 (1)
FCC Part 15.249 (1)
EN 300 220-2 V2.4.1 (2)
EN 301 489-01 V1.9.2 (2)
EN 301 489-03 V1.4.1 (2)
Data rate 250 kbps
Conducted
Output power
6 dBm
1. FCC standards are only applicable to the SPSGRF-915 module.
2. EN standards are only applicable to the SPSGRF-868 module.
