Module RF typical performances
The RF performances of the SPSGRF-868 and SPSGRF-915 modules are depending from many
factors, related to the Customer hardware application board where the module is connected and
also to the Customer application firmware. To give some basic information to the Customer which
will be the module integrator, may be useful to furnish the RF measures taken in an anechoic
chamber using a dongle with inside connected the SPSGRF-868 or the SPSGRF-915 module.
SPSGRF-868 or 915 modules radiated typical performances
Symbol
Parameter
T
est Conditions
Typ.
Unit
Tx RF
power
RF radiated
power
Operating mode
Tx , +11.6 dBm , 2-FSK , 868,0-868,6 MHz
5.3 dBm
Operating mode
Tx , +11.6 dBm , 2-FSK , 902-928 MHz
2.2 dBm
SPSGRF-868 or 915 modules conducted typical performances before the RF
antennas circuits (positive RF power signal values measured)
Parameter Test Condition
Conducted
Programmable
Value
Measured
conducted value
Typ.
Unit
Tx RF
Conducted
Power
(before the
Antennas
circuits)
Operating mode
Tx , +11.6 dBm , 2-FSK , 868 MHz
Tx , +11.6 dBm , 2-FSK , 915 MHz
11.6 11.2 dBm
Operating mode
Tx , +11 dBm , 2-FSK , 868 MHz
Tx , +11 dBm , 2-FSK , 915 MHz
11.0 10.8 dBm
Operating mode
Tx , +10 dBm , 2-FSK , 868 MHz
Tx , +10 dBm , 2-FSK , 915 MHz
10.0 9.7 dBm
Operating mode
Tx , +9 dBm , 2-FSK , 868 MHz
Tx , +9 dBm , 2-FSK , 915 MHz
9.0 8.5 dBm
Operating mode
Tx , +8 dBm , 2-FSK , 868 MHz
Tx , +8 dBm , 2-FSK , 915 MHz
8.0 7.6 dBm
Operating mode
Tx , +7 dBm , 2-FSK , 868 MHz
Tx , +7 dBm , 2-FSK , 915 MHz
7.0 7.2 dBm
Operating mode
Tx , +6 dBm , 2-FSK , 868 MHz
Tx , +6 dBm , 2-FSK , 915 MHz
6.0 6.2 dBm
Operating mode
Tx , +5 dBm , 2-FSK , 868 MHz
Tx , +5 dBm , 2-FSK , 915 MHz
5.0 5.4 dBm
Operating mode
Tx , +4 dBm , 2-FSK , 868 MHz
Tx , +4 dBm , 2-FSK , 915 MHz
4.0 4.0 dBm
Operating mode
Tx , +3 dBm , 2-FSK , 868 MHz
Tx , +3 dBm , 2-FSK , 915 MHz
3.0 3.1 dBm
Operating mode
Tx , +2 dBm , 2-FSK , 868 MHz
Tx , +2 dBm , 2-FSK , 915 MHz
2.0 2.1 dBm
Operating mode
Tx , +1 dBm , 2-FSK , 868 MHz
Tx , +1 dBm , 2-FSK , 915 MHz
1.0 1.2 dBm
Operating mode
Tx , +0 dBm , 2-FSK , 868 MHz
Tx , +0 dBm , 2-FSK , 915 MHz
0.0 0.6 dBm
