User's Manual

SPSGRF
P a g e | 10 Rev 1.0
SPSGRF-868 or 915 modules conducted typical performances before the RF
antennas circuits (negative RF power signal values measured)
Parameter Test Condition
Conducted
Programmable
Value
Measured
conducted value
Typ.
Unit
Tx RF
Conducted
Power
(before the
Antennas
circuits)
Operating mode
Tx , -1 dBm , 2-FSK , 868 MHz
Tx , -1 dBm , 2-FSK , 915 MHz
-1.0 -1.1 dBm
Operating mode
Tx , -2 dBm , 2-FSK , 868 MHz
Tx , -2 dBm , 2-FSK , 915 MHz
-2.0 -2.3 dBm
Operating mode
Tx , -3 dBm , 2-FSK , 868 MHz
Tx , -3 dBm , 2-FSK , 915 MHz
-3.0 -3.4 dBm
Operating mode
Tx , -4 dBm , 2-FSK , 868 MHz
Tx , -4 dBm , 2-FSK , 915 MHz
-4.0 -4.9 dBm
Operating mode
Tx , -5 dBm , 2-FSK , 868 MHz
Tx , -5 dBm , 2-FSK , 915 MHz
-5.0 -5.8 dBm
Operating mode
Tx , -6 dBm , 2-FSK , 868 MHz
Tx , -6 dBm , 2-FSK , 915 MHz
-6.0 -6.9 dBm
Operating mode
Tx , -7 dBm , 2-FSK , 868 MHz
Tx , -7 dBm , 2-FSK , 915 MHz
-7.0 -6.5 dBm
Operating mode
Tx , -8 dBm , 2-FSK , 868 MHz
Tx , -8 dBm , 2-FSK , 915 MHz
-8.0 -7.3 dBm
Operating mode
Tx , -9 dBm , 2-FSK , 868 MHz
Tx , -9 dBm , 2-FSK , 915 MHz
-9.0 -8.2 dBm
Operating mode
Tx , -10 dBm , 2-FSK , 868 MHz
Tx , -10 dBm , 2-FSK , 915 MHz
-10.0 -9.7 dBm
Operating mode
Tx , -15 dBm , 2-FSK , 868 MHz
Tx , -15 dBm , 2-FSK , 915 MHz
-15.0 -14,6 dBm
Operating mode
Tx , -20 dBm , 2-FSK , 868 MHz
Tx , -20 dBm , 2-FSK , 915 MHz
-20.0 -19.2 dBm
Operating mode
Tx , -25 dBm , 2-FSK , 868 MHz
Tx , -25 dBm , 2-FSK , 915 MHz
-25.0 -23.3 dBm
Operating mode
Tx , -30 dBm , 2-FSK , 868 MHz
Tx , -30 dBm , 2-FSK , 915 MHz
-30.0 -26.2 dBm
Operating mode
Tx , -35 dBm , 2-FSK , 868 MHz
Tx , -35 dBm , 2-FSK , 915 MHz
-35.0 -27.8 dBm
