8.4 SIMPLEX/DUPLEX CHANNEL USE
Refer to the VHF MARINE CHANNEL CHART (page 117) for instructions on
use of simplex and duplex channels.
NOTE
All channels are factory-programmed in accordance with FCC (USA),
Industry Canada (Canada), and International regulations. Mode of op-
eration cannot be altered from simplex to duplex or vice-versa.
8.5 DISPLAY TYPE
The GX2000/GX2150 display can be setup to show displays other than the
default “NORMAL” VHF display by using the procedure below:
NOTE
1. By default the COG in “NORMAL” and “COMPASS” displays and
BRG in “AIS”, “COMPASS”, and “WAYPOINT” displays are set to
“True”, however this may be change to magnetic by following the
steps in section “10.9 MAGNETIC”.
2. The “GPS STATUS” display is only available on the GX2150. For this
display to operate correctly, the GX2150 must be connected to a GPS
Chart plotter which outputs NMEA 0183 GSA and GSV sentences.
1. Press and hold down the key until
“Setup Menu” appears, then select “GENERAL
SETUP” with the CHANNEL knob.
2. Press the soft key, then rotate the
CHANNEL knob to select “DISPLAY”.
3. Press the soft key.
4. Rotate the CHANNEL knob to select desired
screen “NORMAL”, “AIS”, “COMPASS”,
“WAYPOINT”, or “GPS STATUS”.
5. Press the soft key to store the selected setting.
“NORMAL” DISPLAY
1
“COMPASS” DISPLAY
1
“AIS” DISPLAY
1
“GPS STATUS” DISPLAY
2
“WAYPOINT” DISPLAY
