User Manual

GX2000/GX2150Page 40
8.12 INTERCOM OPERATION
To access the following Intercom functions one of the soft keys must be setup
as IC. Refer to section “10.14 SOFT KEYS”.
In addition an optional RAM3
(
CMP30
)
Remote Station Microphone must be
connected to perform intercom functions between the GX2000/GX2150 and
the RAM3
(
CMP30
)
.
8.12.1 Communication
1. Press the one of the soft keys momentarily, then
press the soft key to enable the intercom
mode.
Note: Depending on the programming of the
soft key, the soft key may have to be pressed to see the
soft key.
2. When the intercom mode is enabled, “Intercom” is displayed on the radio
and RAM3
(
CMP30
)
Remote
Station Microphone.
3. Press the PTT switch on the
radio. “Talk” will be shown on
the display.
Note: A warning beep will be
heard when the Radios PTT
and RAM3
(
CMP30
)
PTT are
pushed at the same time.
4. Speak slowly and clearly into
the microphone, hold the mi-
crophone about 1/2 inch away from your mouth.
5. When finished, release the PTT switch.
6. Press the key to exit intercom mode and revert to radio mode.
8.12.2 Calling
Press and holding the soft key when in intercom mode on either the
GX2000/GX2150 or RAM3
(
CMP30
)
Remote Station Microphone will produce
a calling beep to the other station.
(
RAM3’s PTT switch is pressed
)
GX2000/GX2150 RAM3
(
GX2000/GX2150’s PTT switch is pressed
)
GX2000/GX2150 RAM3
