NOTE: Your furniture may have different design features than those shown in the drawing.

A-1243

-051 LIFT LID

-031 LIFT LID

CORD ACCESS

For cord access remove the lift lid

panel from the -51 deck and the

lid from the -31 entertainment

console.

Run cords thru the grommets

located in the center of the lift lids.

Replace the lift lid panels by

placing them back into the case.

REMOVABLE PARTITIONS

To install REMOVABLE PARTITIONS,

locate WIRE SUPPORTS in the Upper and

Lower Shelves. Align Grooves in the Top

and Bottom Edges of the PARTITIONS

with the WIRE SUPPORTS, and carefully

slide the PARTITIONS between the Upper

and Lower WIRE SUPPORTS (as shown

below).

SHELF

LOWER

SUPPORTS

WIRE

SHELF

UPPER

GROOVE

REMOVABLE

PARTITION

ADJUSTABLE SHELVES

To remove ADJUSTABLE SHELVES,

remove SCREWS from SHELF

SUPPORTS, then carefully lift Shelves

up and out of the Armoire.

To reposition ADJUSTABLE

SHELVES, insert Stem of SHELF

SUPPORTS into Holes as shown.

Rest the SHELF on the SHELF

SUPPORTS, and reinstall SCREWS.

CAREFULLY READ AND

UNDERSTAND ALL

INSTRUCTIONS BEFORE

PROCEEDING!

CAUTION:

(2) OR MORE PERSONS

RECOMMENDED FOR

ASSEMBLY!

Note: If a Power Screwdriver is used, a

"low torque" setting is recommended!

SCREW

SCREWDRIVER

SHELF

SUPPORT
