Appendix B: Specifications
Printing System Ser
ial Impact Dot-Matrix
Printing Speed Pitch Draft (cps/dpi) LQ (cps/dpi)
Pica (10 cpi) 160/120H 53/360H
Elite (12 cpi) 192/120H 64/360H
Semi-condensed (15 cpi (S))
240/120H 80/360H
Semi-condensed
(15 cpi (I)) 120/240H 80/360H
Condensed pica (17 cpi) 136/240H 91/360H
Condensed elite (20 cpi) 160/240H 106/360H
24 cpi (I) 192/240H 127/360H
H: half-dot
(S): Standard mode only
(I): IBM mode only
Print Direction Draft: Bi-directional logic seeking
LQ: Bi-directional logic seeking
Bit-Image: Uni-directional or bi-directional logic seeking
(selectable); Default: uni-directional
Print Head Number of pins: 24
Life: 100 million dots/pin
Line Spacing 1/6”, 1/8”, 7/60”, n/180”, n/360”, 7/72”, n/72”, n/216”
Character Matrix Pitch Draft LQ
Pica (10 cpi) 24
×
9H 24 × 31H
Elite (12 cpi) 24 × 9H 24 × 27H
Semi-condensed (15 cpi (S)) 16 × 7H 16 × 21H
Semi-condensed (15 cpi (I)) 24 × 9H 24 × 16H
Condensed pica (17 cpi) 24 × 9H 24 × 16H
Condensed elite (20 cpi) 24 × 9H 24 × 16H
24 cpi (I) 24 × 9H 24 × 14H
H: half-dot
(S): Standard mode only
(I): IBM mode only
Environment Operating Temperature: 50 ° F to 95 ° F (10 ° C to 35 ° C)
Storage Temperature: –22 ° F to 149 ° F (–30 ° C to 65 ° C)
Operating Humidity: 30% to 80% (non-condensing)
Storage Humidity: 20% to 90% (non-condensing)
Annexe B: Caractéristiques techniques
Système d’impression Matriciel à impact série
Vitesse d’impression
Pas
Draft
(car/sec/points/pouce)
LQ
(car/sec points/pouce)
Pica (10 car/pouce) 160/120H 53/360H
Elite (12 car/pouce) 192/120H 64/360H
Semi-condensed
(15 car/pouce S))
240/120H 80/360H
Semi-condensed
(15 car/pouce (I))
120/240H 80/360H
Condensed pica
(17 car/pouce)
136/240H 91/360H
Condensed elite
(20 car/pouce)
160/240H 106/360H
24 car/pouce (I) 192/240H 127/360H
D: demi-point
(S): mode standard uniquement
(I): mode IBM uniquement
Impression Graphique Draft: Recherche logique bidirectionnelle
LQ: Recherche logique bidirectionnelle
Image binaire: Recherche logique bidirectionnelle ou
unidirectionnelle (pouvant être sélectionnée);
unidirectionnelle par défaut
Tête d’impression Nombre d’aiguilles: 24
Durée: 100 millions de points/aiguille
Espacement des lignes 1/6 pouces, 1/8 pouces, 7/60 pouces, n/180 pouces, n/360 pouces, 7/72
pouces, n/72 pouces, n/216 pouces
Matrice de caractères Pas Draft LQ
Pica (10 car/pouce) 24
× 9D 24 × 31H
Elite (12 car/pouce) 24 × 9H 24 × 27H
Semi-condensed
(15 car/pouce (S))
16 × 7H 16 × 21H
Semi-condensed
(15 car/pouce (I))
24 × 9H 24 × 16H
Condensed pica
(17 car/pouce)
24 × 9H 24 × 16H
Condensed elite
(20 car/pouce)
24
× 9H 24 × 16H
24 car/pouce (I) 24 × 9H 24 × 14H
D : demi-point
(S) : mode standard uniquement
(I) : mode IBM uniquement
Environnement Température d’exploitation:10 à 35 ° C
Température de stockage: –30 à 65 ° C
Humidité d’exploitation: 30 à 80 % (sans condensation)
Humidité de stockage: 20 à 90 % (sans condensation)
