Special Print Mode Commands
Bit Image Graphic Commands
Description Mode ASCII Code
Set master print mode STD ESC!
Cancel underlining Both ESC-0
Select underlining Both ESC-1
Select emphasized print Both ESC E
Cancel emphasized print Both ESC F
Select double-strike print Both ESC G
Cancel double-strike print Both ESC H
Select superscripts Both ESC S0
Select subscripts Both ESC S1
Cancel super/subscripts Both ESC T
Cancel upperlining IBM ESC _0
Select upperlining IBM ESC _1
Cancel character style mode STD ESC q0
Select outline print STD ESC q1
Select shadow print STD ESC q2
Select outline and shadow print STD ESC q3
Description Mode ASCII Code
Select bit image mode STD ESC *m n1 n2
Redefine bit image mode STD ESC ?
8-pin single-density bit image Both ESC K n1 n2
8-pin double-density bit image Both ESC L n1 n2
8-pin double-density bit image, double-speed Both ESC Y n1 n2
8-pin quadruple density bit image Both ESC Z n1 n2
Select graphic mode IBM ESC [g
Line Spacing Commands
Form Feed and Related Commands
Download Character Commands
Description Mode ASCII Code
Advance paper one line (line feed) Both LF
Reverse paper one line STD ESC LF
Set line spacing to 1/8 ″ Both ESC 0
Set line spacing to 7/72 ″ IBM ESC 1
Set line spacing to 1/6 ″ STD ESC 2
Execute ESC A IBM ESC 2
Set line spacing to n /180 ″ (STD/IBM), n /216 ″ (IBM), or n /
360 ″ (IBM)
Both
ESC 3 n
Set line spacing to n /360 ″ STD ESC + n
Set line spacing to n /60 ″ STD ESC A n
Define line spacing to n /72 ″ IBM ESC A n
One time feed of n /180 ″ (STD/IBM), n /216 ″ (IBM), or n /360 ″
(IBM)
Both
ESC J n
Reverse line feed IBM ESC ]
One time reverse feed of n /180 ″ STD ESC j n
Description Mode ASCII Code
Advance paper to top of next page (form feed) Both FF
Set top of form to current position IBM ESC 4
Set page length to n inches Both ESC C 00H n
Set page length to n lines Both ESC C n
Set base unit of line spacing ( n /180 ″ , n /216 ″ , n /360 ″ ) IBM ESC [\
Description Mode ASCII Code
Cancel download character set STD ESC %0
Select download character set STD ESC %1
Define download characters in RAM STD ESC &00H
