Appendix E: Printer Control Codes / Annexe E: Codes de commande d’imprimante
Anhang E: Steuercodes des Druckers / Appendice E: Codici di controllo della stampante
Print Pitch Control Commands
Top/Bottom Margin and Vertical Tab Commands
Description Mode ASCII Code
Select one line expanded print Both
SO
Same as SO Both ESC SO
Select condensed print Both SI
Same as SI Both ESC SI
Cancel condensed print STD DC2
Set print pitch to pica IBM DC2
Cancel one-line expanded print Both DC4
Set print pitch to elite IBM ESC :
Set print pitch to elite STD ESC M
Set print pitch to pica STD ESC P
Cancel proportional print IBM ESC P00H
Select proportional print IBM ESC P01H
Cancel expanded print Both ESC W0
Select expanded print Both ESC W1
Set print pitch to 15 CPI STD ESC g
Cancel proportional print STD ESC p0
Select proportional print STD ESC p1
Description Mode ASCII Code
Advance paper to next vertical tab position Both VT
Select VFU channels STD ESC /
n
Set vertical tab positions Both ESC B n …NULL
Set bottom margin Both ESC N n
Cancel bottom margin Both ESC O
Set all tabs to power on defaults IBM ESC R
Set VFU in a channel STD ESC b n m…NULL
This appendix lists the printer’s control commands. It gives the name of each
control command, along with the applicable emulation mode (Standard, IBM,
or Both), and the applicable ASCII code.
Font and Character Set Control Commands
Description Mode ASCII Code
Select italic STD ESC 4
Cancel italic STD ESC 5
Select Character Set #2 Both ESC 6
Select Character Set #1 Both ESC 7
Select Draft 10 CPI IBM ESC I00H
Select Draft 12 CPI IBM ESC I08H
Select Draft 17 CPI IBM ESC I10H
Select LQ 10 CPI IBM ESC I02H
Select LQ 12 CPI IBM ESC I0AH
Select LQ 17 CPI IBM ESC I12H
Select Proportional LQ IBM ESC I03H
Select international character set STD ESC R n
Set Code Page Both ESC [T
Set print quality IBM ESC [d
Print characters from all character chart IBM ESC \ n1 n2
Print one character from all character chart IBM ESC ^ n
Select Standard Character Table Both ESC t0
Select IBM Character Table Both ESC t1
Set download characters in “00H - 7FH” area to “80H - FFH.” STD ESC t2
Select Draft Mode STD ESC x0
Select LQ Mode STD ESC x1
