Horizontal Print Position Control Commands
Description Mode ASCII Code
Move print head to next horizontal tab position Both HT
Return print head to left margin (carriage return) Both CR
Move print head to absolute horizontal position STD ESC $ n1 n2
Add n dot spaces between characters STD ESC SPn
Cancel automatic line feed IBM ESC 500H
Select automatic line feed IBM ESC 501H
Set horizontal tab positions Both ESC D n …NULL
Set right margin STD ESC Q n
Set left and right margins IBM ESC X n1 n2
Move print head to specified horizontal position STD ESC \ n1 n2
Move print position to right IBM ESC d
Set left margin STD ESC l n
Other Commands
Description Mode ASCII Code
Sound printer bell Both BEL
Move printer head back one space (backspace) Both BS
Set printer on line Both DC1
Set printer off line STD DC3
Cancel line in print buffer Both CAN
Delete last character sent STD DEL
ASF control Both ESC EM n
Cancel MSB control STD ESC #
Select score STD ESC (-
One-line uni-directional printing STD ESC <
Set MSB to logical 0 STD ESC =
Set MSB to logical 1 STD ESC >
Initialize printer Both ESC @
Deselect printer IBM ESC Q n
NEC Commands
Cancel uni-directional printing Both ESC U0
Select uni-directional printing Both ESC U1
Control character height, width, line spacing IBM ESC [@
Set initial condition IBM ESC [K
Ignored STD ESC h n
Stop printing IBM ESC j
Select printing color Both ESC r n
Cancel double-high mode STD ESC w0
Select double-high mode STD ESC w1
Ignored STD ESC ~ n
Description Mode ASCII Code
Set line spacing to
n /360 ″ STD FS 3 n
Initialize printer STD FS @
Cancel expanded printing STD FS E0
Select expanded printing STD FS E1
Select expanded (triple-width) printing STD FS E2
Select forward feed STD FS F
Select standard character table STD FS I0
Select IBM character table STD FS I1
Move download characters in 00H-7FH area to 80H-FFH STD FS I2
Select reverse feed STD FS R
Cancel double-height mode STD FS V0
Select double-height mode STD FS V1
24-pin hex density bit image STD FS Z
Print characters from all character chart STD FS \
Print one character from all character chart STD FS ^
