AppendixA.frame Black #8
88
Anleitung zur Fehlerbehebung
Die folgende Tabelle dient zur Feststellung der Ursache von Problemen und zur
Ermittlung der besten Maßnahmen zur Behebung des Problems.
Problem Mögliche Ursache Lösung
Die READY-Anzeige leuchtet
oder blinkt nicht.
Der Drucker erhält keinen
Netzstrom.
Prüfen, ob das Netzkabel
ordnungsgemäß in die
Netzsteckdose eingesteckt
ist.
Durch Herausziehen des
Netzsteckers und Anschluß
eines anderen Gerätes
überprüfen, ob die
Stromquelle in Ordnung ist.
Es klingt, als ob der
Druckvorgang läuft, aber der
Drucker druckt nicht.
Druck ist schwach
ausgebildet.
Das Farbband staut, ist
verdreht oder nicht
ordnungsgemäß zwischen
Druckkopf und
Druckkopfführung eingelegt.
Vergewissern, daß die
Farbbandkassette richtig
eingesetzt ist. Siehe dazu
“Über Farbbandkassetten” auf
Seite 6.
Der Drucker ist nicht richtig
auf die verwendete
Papierstärke eingestellt.
Stellen Sie den Drucker auf
die von Ihnen verwendete
Papierstärke ein. Siehe dazu
“Einstellen der Papierstärke”
auf Seite 72.
Druckertest arbeitet, aber
Drucker druckt Daten vom
angeschlossenen Computer
nicht aus.
Die falsche Emulation wurde
gewählt.
Überprüfen Sie die Wahl der
Emulation und ändern Sie
diese, falls notwendig. Siehe
dazu “Emulation” auf Seite
32.
Ihr Anwendungsprogramm
oder die System-Software
Ihres Druckers wurden falsch
gewählt.
Überprüfen Sie die Wahl des
Druckers in Ihrem
Anwendungsprogramm.
Die System-Software des
Computers ist nicht
ordnungsgemäß für den
Drucker oder für die
verwendete Art des
Anschlußkabels eingerichtet.
Einstellungen der System-
Software überprüfen.
Guida alla risoluzione dei problemi
Consultate la seguente tabella per individuare più agevolmente le cause degli
inconvenienti e stabilire il rimedio più opportuno da adottare.
Problema Possibile causa Operazione consigliata
L’indicatore READY non è né
acceso né lampeggiante.
La stampante non riceve
corrente.
Controllate che il cavo di
alimentazione sia inserito
correttamente nella presa
elettrica.
Controllate che arrivi
corrente alla presa elettrica
staccando la stampante e
collegandovi un altro
dispositivo elettrico.
La stampante emette un
rumore come se stampasse,
ma non viene eseguita
nessuna stampa.
La stampa è sbiadita.
Il nastro è inceppato,
attorcigliato oppure non è
inserito correttamente fra la
testina di stampa e la
piastrina di protezione.
Accertatevi che la cartuccia
nastro sia installata
correttamente. Vedere la
sezione “Due parole sulle
cartucce nastro” a pagina 6.
La regolazione della distanza
di stampa sulla stampante
non corrisponde al tipo di
carta che state utilizzando.
Regolate la stampante per lo
spessore della carta che state
utilizzando. Vedere la
sezione “Regolazione della
distanza di stampa ” a pagina
72.
Il test della stampante
funziona, ma la stampante
non stampa i dati provenienti
dal computer a cui è
collegata.
E’ stata selezionata
un’emulazione sbagliata.
Controllate l’emulazione
selezionata e, se necessario,
cambiatela. Vedere il
paragrafo “Emulazione” a
pagina 32.
La stampante selezionata
all’interno della vostra
applicazione o del software di
sistema è sbagliata.
Controllate la stampante
selezionata nella vostra
applicazione.
Il software di sistema del
computer non è configurato in
maniera appropriata per la
stampante oppure per il cavo
d’interfaccia utilizzato.
Controllate i parametri di
configurazione del software di
sistema.
