CardBus Serial Card 4 Port CardBus 16950 Serial Card CB4S950 Instruction Manual Actual product may vary from photo
FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Instruction Manual Table of Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Contents . . . . . . . . . . . . . .
Instruction Manual Introduction Thank you for purchasing a StarTech.com 4 port CardBus 16950 Serial Card. This card allows users to add multiple serial ports to their laptop computer, using an available CardBus slot, for seamless use with serial peripherals, including printers, scanners and more.
Instruction Manual Installation Port 1 (DB9 Male) Port 2 (DB9 Male) Port 3 (DB9 Male) 68-pin CardBus connector Port 4 (DB9 Male) Windows XP 1. With the notebook PC powered on and fully booted, insert the PCMCIA Card into an available CardBus slot on your notebook PC. 2. This will launch the Add New Hardware Wizard, which will guide you through the installation process. On the first screen, click Next to continue.
Instruction Manual Click Next to continue. 3. Insert the Driver CD into the CD/DVD-ROM drive, and select Search for a suitable driver for my device (Recommended), and click Next. 4. Select Specify a location, and click Next to continue. Click Browse to specify the location of the driver file (D:\IO\OXFORD, where D:\ specifies the location of the CD/DVD-ROM drive). 5. Click Next to continue, and click Yes to skip the digital signature process.
Instruction Manual Accessory Products from StarTech.com Contact your local StarTech.com dealer or visit www.startech.com for cables or other accessories that will help you get the best performance out of your new product. MC3MF 3 ft. AT Modem Cable DB9F-DB25M MC6MF 6 ft. AT Modem Cable (male to female) MXT100 6 ft. 9-pin Straight Through Cable (male to female) MXT100_25 25 ft.
Instruction Manual Technical Support StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of online tools, documentation, and downloads. Warranty Information This product is backed by a lifetime warranty. In addition, StarTech.
About StarTech.com StarTech.com is “The Professionals’ Source for Hard-to-Find Computer Parts”. Since 1985, we have been providing IT professionals with the quality products they need to complete their solutions. We offer an unmatched selection of computer parts, cables, server management solutions and A/V products and serve a worldwide market through our locations in the United States, Canada, the United Kingdom and Taiwan. Visit www.startech.
