USB 3.0 to 7mm high 2.5in SATA III Hard Drive Enclosure w/ UASP S2510BPU337 *actual product may vary from photos DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.
FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Table of Contents Product Diagram................................................................1 Front View......................................................................................................................1 Rear View........................................................................................................................1 Introduction....................................................................... 2 Packaging Contents...............................................
Product Diagram Front View Enclosure Cover Lock/Release switches Rear View USB 3.
Introduction Packaging Contents • 1x USB 3.0 to 2.5” SSD/HDD Enclosure • 1x USB 3.0 Cable • 1x Installation pad for 5mm drives • 1x Install Guide System Requirements • Computer system with available USB 3.0 (5 Gbit/s) port or USB 2.0 port (480Mbps) • 7mm 2.5” SATA Solid State Drive (SSD) / Hard Drive (HDD) • Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7/8/8.1 (32/64-bit), or Apple® Mac® OS 9.
Hardware Installation WARNING! Hard drives and storage enclosures require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Be sure that you are properly grounded by wearing an anti-static strap when handling computer components or discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds.
3. Connect your 2.5” SATA SSD/HDD to the SATA connector on the drive tray. Note: The enclosure tray has built-in drive positioning pegs, to help ensure the drives proper position within the housing. Ensure the drive is aligned with these pegs before attempting to replace the cover.
4. Place the top cover back into the drive tray in the same manor it was removed, and slide each of the cover Lock/Release switches back to the inside of the enclosure toward the lock indicator. 5. Complete installation by connecting the included USB cable from the USB 3.0 Micro type B port on the enclosure to an available USB port on the computer system.
Powering the Drive Enclosure The hard drive enclosure requires no external power supply, as it is capable of receiving enough power from the USB Bus to which it is connected. LED Indicator The hard drive enclosure offers an LED indicator, to enable you to monitor drive activity. When the enclosure is powered, the LED will illuminate. While the hard drive is being accessed, the LED will blink.
all windows are closed, click on the USB storage icon on the desktop, and drag it to the Trash Can icon on the desktop. Allow 5 seconds before physically removing the enclosure/drive from the computer. Initializing the Hard Drive 1. If the SATA Hard Drive is blank it may need to be initialized and formatted before use. From the main Windows desktop, right-click on “My Computer” (“Computer” in Vista/ 7 / 8/ 8.1), then select Manage.
4. Follow the on screen prompts to initialize the drive in the format of your choice. Specifications Host Interface USB 3.0 External Connectors 1 x USB 3.0 Micro B 1 x 15 pin SATA Power female Internal Connectors 1 x 7 pin SATA Data male Maximum Data Transfer Rate USB 3.0: 5 Gbit/s Compatible Operating Systems Windows 2000/XP/Server 2003/ Vista/Server 2008 R2/7/8/8.
Technical Support StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of online tools, documentation, and downloads. For the latest drivers/software, please visit www.startech.com/ downloads Warranty Information This product is backed by a two year warranty. In addition, StarTech.
