Manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 08/01/2012
For the most up-to-date information, please visit: www.startech.com
DP2DVID2
DisplayPort® to DVI Dual Link Active Adapter
*actual product may vary from photos
Packaging Contents
• 1xDP2DVID2adapter
• 1xInstallationGuide
System Requirements
• DisplayPort®enabledcomputersystem/videocard
• AvailableUSBport
• DVI-D(digital)enableddisplaydevice(i.e.monitor,
projector,HDTV,etc)
Specications
Connectors
1xDisplayPort®male
1xUSBtypeAmale
1xDVI-Dfemale
Maximum Video Resolution
Support
2560x1600
Cable Length
USB:18”
DisplayPort:14.5”
Dimensions 105.5mmx58.0mmx22.0mm
Weight 175g
Installation
1. Withthecomputersystempoweredo,plugthe
DisplayPort®connectorfromtheDP2DVIDadapter
intothecomputer’svideocard.
2. ConnecttheUSBconnectorfromtheDP2DVID
adapterintoaUSBportonthecomputersystem.
3. ConnectaDVI-D(digital)cablefromtheDP2DVID
adaptertoyourdisplay.
NOTE:For2560x1600operation,aduallinkDVI-Dcable
mustbeused.
4. Poweronthemonitorfollowedbythecomputer
system.Nosoftware/driverinstallationisrequired.
