Technical Specifications
Warranty 2 Years
Audio Yes
Cabling Cat 5e UTP or better
Daisy-Chain Yes
Ports 1
Rack-Mountable Yes
Connector Type(s) 1 - HDMI (19 pin)
Connector Type(s) 1 - RJ-45
Local Unit Connectors 1 - HDMI (19 pin)
Local Unit Connectors 1 - RJ-45
Remote Unit Connectors 1 - HDMI (19 pin)
Remote Unit Connectors 1 - RJ-45
Audio Specifications Stereo Sound
Max Distance 100 m / 330 ft
Maximum Digital Resolutions 1920x1200 @60Hz
Supported Resolutions 1920 x 1200 (1080p)
Wide Screen Supported Yes
Color Black
Enclosure Type Aluminum
Product Height 1.1 in [28 mm]
Product Length 5.1 in [130 mm]
Product Weight 15.8 oz [448 g]
Product Width 3.8 in [97 mm]
LED Indicators 1 - Link OK / POWER - Transmitter
LED Indicators 1 - Reset - Transmitter
LED Indicators 1 - Link OK / POWER - Receiver
LED Indicators 1 - Reset - Receiver
Center Tip Polarity Positive
Input Current 0.4 A
Input Voltage 100 ~ 240 AC
Output Current 2 A
Output Voltage 5 DC
Plug Type M
Power Adapter Included Yes
Humidity 0% - 80 %
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Shipping (Package) Weight 4.3 lb [1.9 kg]
