PRODUCT CATALOGUE - STEGO
COMPACT HIGH-PERFORMANCE FAN HEATER
CR 030 | 950 W
The compact high performance fan heater prevents formation of condensation and frost and provides an evenly
distributed interior air temperature in enclosures with electric/electronic components. The plastic housing provi des
double insulation and acts as protection against contact. The fan heater is available with integrated thermostat
or pre-set hygrostat for temperature or humidity control. The CR 030 was designed as a stationary unit for the
bottom of the enclosure. For wall fixing the fan heater CR 130 is recommended.
> Compact design
> Double insulated
> Integrated thermostat or hygrostat
Connection diagram
TECHNICAL DATA
Heating element high performance cartridge
Temperature safety cut-out with automatic reset and second-tier one shot fuse to protect
against overheating in case of fan failure
Heater body extruded aluminium profile
Axial fan, ball bearing airflow 160 m³/h, free flow
service life 50,000 h at +25 °C (+77 °F)
Connection 2-pole max. 2.5 mm², clamping screw with strain relief,
torque 0.8 Nm max.
Casing plastic according to UL94 V-0, black
Mounting screw fixing (M5)
Fitting position vertical airflow (air outlet up)
Dimensions 168 x 145 x 100 mm
Weight approx. 1.4 kg
Operating¹/Storage temperature -45 to +70 °C (-49 to +158 °F)
Operating/Storage humidity max. 90 % RH (non-condensing)
Protection type/Protection class IP20 / II (double insulated)
Note other heating capacities from 200 W up available on request
¹ Operating temperature of heater with integrated hygrostat: 0 to +60 °C (+32 to +140 °F).
Art. No. Model Operating voltage Heating capacity Recommended
pre-fuse T (time-delay)
Setting range² Approvals
03051.0-00 Fan Heater with thermostat AC 230 V, 50/60 Hz 950 W 6.3 A 0 to +60 °C VDE UL File No. E234324 EAC
03051.0-02 Fan Heater with hygrostat AC 230 V, 50/60 Hz 950 W 6.3 A 65 % RH, factory-set VDE UL File No. E234324 EAC
03059.9-00 Fan Heater with thermostat AC 120 V, 50/60 Hz 950 W 10.0 A +32 to +140 °F - UL File No. E234324 EAC
² Switch temperature difference 7 K (±4 K tolerance)
HEATING
04.04.2017 | Specifications are subject to change without notice. Errors and omissions excepted. Suitability of this product for its intended use and any associated risks must be determined by the end customer/buyer in its final application. www.stego.de | www.stego.co.uk | www.stegonorden.se
