DocID025833 Rev 9 41/61
UM1724 Hardware layout and configuration
60
Table 19. Arduino connectors on NUCLEO-F410RB
CN No. Pin No. Pin name MCU pin Function
Left connectors
CN6
power
1NC - -
2 IOREF - 3.3V Ref
3 RESET NRST RESET
4 +3V3 - 3.3V input/output
5 +5V - 5V output
6 GND - Ground
7 GND - Ground
8 VIN - Power input
CN8
analog
1 A0 PA0 ADC1_0
2 A1 PA1 ADC1_1
3 A2 PA4 ADC1_4
4 A3 PB0 ADC1_8
5 A4 PC1 or PB9
(1)
ADC1_11 (PC1) or I2C1_SDA (PB9)
6 A5 PC0 or PB8
(1)
ADC1_10 (PC0) or I2C1_SCL (PB8)
Right connectors
CN5
digital
10 PB8 D15 I2C1_SCL
9 PB9 D14 I2C1_SDA
8- AREF AVDD
7 - GND Ground
6 PA5 D13 SPI1_SCK
5 PA6 D12 SPI1_MISO
4 PA7 D11 TIM1_CH1N || SPI1_MOSI
3 PB6 D10 SPI1_CS
2PC7 D9 -
1PA9 D8 -
CN9
digital
8PA8 D7 -
7 PB10 D6 -
6 PB4 D5 -
5 PB5 D4 -
4 PB3 D3 -
3PA10 D2 -
2 PA2 D1 USART2_TX
1 PA3 D0 USART2_RX
